| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_141T01_9000003174_21500cztM0_level2.evt | modeM0/AS1T03_141T01_9000003174_21500cztM0_level2_quad_clean.evt |
| Size (bytes) | 580,769,280 | 106,750,080 |
| Size | 553.9 MB | 101.8 MB |
| Events in quadrant A | 3,496,806 | 686,504 |
| Events in quadrant B | 3,650,062 | 698,602 |
| Events in quadrant C | 3,516,848 | 679,080 |
| Events in quadrant D | 6,420,248 | 650,547 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15344 | 0 |
| B | 0 | 15674 | 0 |
| C | 0 | 15372 | 0 |
| D | 0 | 24244 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7448 | 39 | 0.523631% |
| B | 7449 | 56 | 0.751779% |
| C | 7449 | 64 | 0.859176% |
| D | 7448 | 523 | 7.022019% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7753 | 7448 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7754 | 7449 | 3 | 3 | 0.04% | 0.04% |  |
| C | 7754 | 7449 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7753 | 7448 | 421 | 421 | 5.43% | 5.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12439 | 63.6 | 904 | 886 | 181.7 |
| A | 3 | 1 | 9581 | 47.87 | 904 | 886 | 181.7 |
| A | 0 | 226 | 7885 | 38.53 | 904 | 886 | 181.7 |
| B | 0 | 230 | 44016 | 246.64 | 902 | 879 | 174.9 |
| B | 0 | 190 | 25247 | 139.33 | 902 | 879 | 174.9 |
| B | 0 | 189 | 22853 | 125.64 | 902 | 879 | 174.9 |
| C | 14 | 238 | 134935 | 656.59 | 865 | 870 | 204.2 |
| C | 13 | 61 | 6038 | 25.31 | 865 | 870 | 204.2 |
| C | 7 | 220 | 4455 | 17.56 | 865 | 870 | 204.2 |
| D | 5 | 222 | 1374105 | 6112.55 | 853 | 832 | 224.7 |
| D | 1 | 52 | 1103628 | 4908.63 | 853 | 832 | 224.7 |
| D | 14 | 35 | 328407 | 1458.06 | 853 | 832 | 224.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
