| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_141T01_9000003174_21504cztM0_level2.evt | modeM0/AS1T03_141T01_9000003174_21504cztM0_level2_quad_clean.evt |
| Size (bytes) | 491,544,000 | 94,610,880 |
| Size | 468.8 MB | 90.2 MB |
| Events in quadrant A | 3,359,985 | 593,083 |
| Events in quadrant B | 3,560,109 | 608,766 |
| Events in quadrant C | 3,433,044 | 591,096 |
| Events in quadrant D | 4,045,104 | 571,651 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14614 | 0 |
| B | 0 | 15023 | 0 |
| C | 0 | 14650 | 0 |
| D | 0 | 16897 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7188 | 42 | 0.584307% |
| B | 7188 | 52 | 0.723428% |
| C | 7188 | 58 | 0.806900% |
| D | 7188 | 109 | 1.516416% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9063 | 7190 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9063 | 7190 | 5 | 5 | 0.06% | 0.07% |  |
| C | 9063 | 7190 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9063 | 7190 | 64 | 64 | 0.71% | 0.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12097 | 64.01 | 870 | 851 | 175.7 |
| A | 0 | 226 | 7378 | 37.15 | 870 | 851 | 175.7 |
| A | 3 | 137 | 7355 | 37.02 | 870 | 851 | 175.7 |
| B | 3 | 64 | 35796 | 208.18 | 879 | 857 | 167.8 |
| B | 0 | 230 | 26948 | 155.46 | 879 | 857 | 167.8 |
| B | 12 | 111 | 20270 | 115.67 | 879 | 857 | 167.8 |
| C | 14 | 238 | 133638 | 671.17 | 844 | 852 | 197.8 |
| C | 3 | 233 | 6405 | 28.07 | 844 | 852 | 197.8 |
| C | 13 | 61 | 5954 | 25.79 | 844 | 852 | 197.8 |
| D | 14 | 35 | 386305 | 1726.82 | 840 | 822 | 223.2 |
| D | 13 | 174 | 211736 | 944.81 | 840 | 822 | 223.2 |
| D | 7 | 38 | 114373 | 508.66 | 840 | 822 | 223.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
