| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_141T01_9000003174_21514cztM0_level2.evt | modeM0/AS1T03_141T01_9000003174_21514cztM0_level2_quad_clean.evt |
| Size (bytes) | 506,471,040 | 99,970,560 |
| Size | 483.0 MB | 95.3 MB |
| Events in quadrant A | 3,393,932 | 639,985 |
| Events in quadrant B | 3,556,237 | 651,421 |
| Events in quadrant C | 3,351,160 | 632,387 |
| Events in quadrant D | 4,554,863 | 608,830 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14615 | 0 |
| B | 0 | 15016 | 0 |
| C | 0 | 14650 | 0 |
| D | 0 | 18352 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7104 | 40 | 0.563063% |
| B | 7105 | 80 | 1.125968% |
| C | 7105 | 76 | 1.069669% |
| D | 7105 | 226 | 3.180859% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7374 | 7105 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7375 | 7106 | 7 | 7 | 0.09% | 0.10% |  |
| C | 7375 | 7106 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7375 | 7106 | 273 | 273 | 3.70% | 3.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 48 | 72907 | 415.06 | 861 | 843 | 173.6 |
| A | 13 | 254 | 11857 | 63.44 | 861 | 843 | 173.6 |
| A | 0 | 226 | 7487 | 38.27 | 861 | 843 | 173.6 |
| B | 0 | 230 | 100887 | 605.99 | 858 | 837 | 165.1 |
| B | 4 | 190 | 27441 | 161.14 | 858 | 837 | 165.1 |
| B | 12 | 111 | 19691 | 114.19 | 858 | 837 | 165.1 |
| C | 14 | 238 | 128408 | 658.35 | 824 | 829 | 193.8 |
| C | 13 | 61 | 5912 | 26.23 | 824 | 829 | 193.8 |
| C | 8 | 128 | 4364 | 18.24 | 824 | 829 | 193.8 |
| D | 7 | 38 | 699381 | 3461.3 | 831 | 806 | 201.8 |
| D | 1 | 52 | 217236 | 1072.37 | 831 | 806 | 201.8 |
| D | 14 | 35 | 164660 | 811.86 | 831 | 806 | 201.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
