| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_094T01_9000003204_21595cztM0_level2.evt | modeM0/AS1A05_094T01_9000003204_21595cztM0_level2_quad_clean.evt |
| Size (bytes) | 468,578,880 | 119,102,400 |
| Size | 446.9 MB | 113.6 MB |
| Events in quadrant A | 3,563,606 | 786,804 |
| Events in quadrant B | 3,406,817 | 824,213 |
| Events in quadrant C | 3,328,587 | 786,718 |
| Events in quadrant D | 3,447,957 | 753,722 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14696 | 2 |
| B | 0 | 14255 | 2 |
| C | 0 | 14020 | 2 |
| D | 0 | 14660 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6533 | 152 | 2.326649% |
| B | 6533 | 47 | 0.719424% |
| C | 6533 | 91 | 1.392928% |
| D | 6533 | 53 | 0.811266% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7863 | 6534 | 106 | 106 | 1.35% | 1.62% |  |
| B | 7863 | 6534 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7863 | 6534 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7863 | 6534 | 24 | 24 | 0.31% | 0.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 321741 | 1928.2 | 841 | 828 | 166.4 |
| A | 13 | 254 | 9364 | 51.29 | 841 | 828 | 166.4 |
| A | 0 | 226 | 7284 | 38.79 | 841 | 828 | 166.4 |
| B | 12 | 111 | 18382 | 111.48 | 853 | 835 | 157.4 |
| B | 0 | 229 | 15937 | 95.94 | 853 | 835 | 157.4 |
| B | 11 | 111 | 15929 | 95.89 | 853 | 835 | 157.4 |
| C | 14 | 238 | 130758 | 684.51 | 820 | 827 | 189.8 |
| C | 13 | 61 | 5695 | 25.65 | 820 | 827 | 189.8 |
| C | 7 | 221 | 2100 | 6.71 | 820 | 827 | 189.8 |
| D | 1 | 52 | 149844 | 758.66 | 815 | 791 | 196.5 |
| D | 13 | 153 | 84933 | 428.27 | 815 | 791 | 196.5 |
| D | 2 | 136 | 77772 | 391.82 | 815 | 791 | 196.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
