| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_094T01_9000003204_21616cztM0_level2.evt | modeM0/AS1A05_094T01_9000003204_21616cztM0_level2_quad_clean.evt |
| Size (bytes) | 522,688,320 | 91,094,400 |
| Size | 498.5 MB | 86.9 MB |
| Events in quadrant A | 3,665,842 | 565,768 |
| Events in quadrant B | 3,725,770 | 574,775 |
| Events in quadrant C | 3,520,592 | 554,703 |
| Events in quadrant D | 4,405,740 | 539,119 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15580 | 2 |
| B | 0 | 15730 | 1 |
| C | 0 | 15325 | 1 |
| D | 0 | 18204 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7530 | 79 | 1.049137% |
| B | 7531 | 101 | 1.341123% |
| C | 7531 | 106 | 1.407516% |
| D | 7531 | 208 | 2.761917% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7835 | 7531 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7836 | 7532 | 11 | 11 | 0.14% | 0.15% |  |
| C | 7836 | 7532 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7836 | 7532 | 90 | 90 | 1.15% | 1.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 166908 | 904.31 | 907 | 885 | 183.6 |
| A | 13 | 254 | 10868 | 54.38 | 907 | 885 | 183.6 |
| A | 3 | 137 | 7808 | 37.71 | 907 | 885 | 183.6 |
| B | 3 | 64 | 74603 | 428.56 | 901 | 879 | 172.0 |
| B | 15 | 36 | 24221 | 135.69 | 901 | 879 | 172.0 |
| B | 0 | 219 | 23876 | 133.68 | 901 | 879 | 172.0 |
| C | 14 | 238 | 135477 | 663.14 | 865 | 868 | 203.0 |
| C | 9 | 54 | 7366 | 32.01 | 865 | 868 | 203.0 |
| C | 13 | 61 | 6047 | 25.51 | 865 | 868 | 203.0 |
| D | 1 | 52 | 453292 | 2122.53 | 870 | 842 | 213.2 |
| D | 13 | 153 | 191978 | 896.66 | 870 | 842 | 213.2 |
| D | 7 | 238 | 151751 | 707.94 | 870 | 842 | 213.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
