| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_002T02_9000003206_21663cztM0_level2.evt | modeM0/AS1A06_002T02_9000003206_21663cztM0_level2_quad_clean.evt |
| Size (bytes) | 539,199,360 | 95,250,240 |
| Size | 514.2 MB | 90.8 MB |
| Events in quadrant A | 3,422,675 | 617,308 |
| Events in quadrant B | 3,446,750 | 629,698 |
| Events in quadrant C | 3,244,822 | 603,957 |
| Events in quadrant D | 5,754,758 | 559,938 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14630 | 2 |
| B | 0 | 14645 | 2 |
| C | 0 | 14010 | 2 |
| D | 0 | 21736 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6794 | 65 | 0.956727% |
| B | 6794 | 66 | 0.971445% |
| C | 6794 | 81 | 1.192228% |
| D | 6794 | 438 | 6.446865% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7714 | 6795 | 19 | 19 | 0.25% | 0.28% |  |
| B | 7714 | 6795 | 7 | 7 | 0.09% | 0.10% |  |
| C | 7714 | 6795 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7714 | 6795 | 389 | 389 | 5.04% | 5.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 247558 | 1492.73 | 820 | 802 | 165.3 |
| A | 3 | 1 | 11852 | 66.85 | 820 | 802 | 165.3 |
| A | 13 | 254 | 8786 | 48.3 | 820 | 802 | 165.3 |
| B | 3 | 64 | 54002 | 337.67 | 823 | 803 | 157.5 |
| B | 0 | 230 | 34197 | 211.96 | 823 | 803 | 157.5 |
| B | 0 | 229 | 31688 | 196.04 | 823 | 803 | 157.5 |
| C | 14 | 238 | 123864 | 656.26 | 796 | 801 | 187.5 |
| C | 10 | 22 | 7807 | 37.36 | 796 | 801 | 187.5 |
| C | 10 | 23 | 6052 | 28.0 | 796 | 801 | 187.5 |
| D | 7 | 223 | 773196 | 4066.6 | 787 | 765 | 189.9 |
| D | 1 | 52 | 756759 | 3980.06 | 787 | 765 | 189.9 |
| D | 13 | 153 | 623983 | 3281.04 | 787 | 765 | 189.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
