| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_002T02_9000003206_21667cztM0_level2.evt | modeM0/AS1A06_002T02_9000003206_21667cztM0_level2_quad_clean.evt |
| Size (bytes) | 576,057,600 | 94,775,040 |
| Size | 549.4 MB | 90.4 MB |
| Events in quadrant A | 3,108,492 | 631,990 |
| Events in quadrant B | 3,310,528 | 660,133 |
| Events in quadrant C | 3,302,676 | 619,190 |
| Events in quadrant D | 7,305,790 | 527,299 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13190 | 2 |
| B | 0 | 13709 | 2 |
| C | 0 | 13739 | 2 |
| D | 0 | 25956 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6176 | 21 | 0.340026% |
| B | 6176 | 43 | 0.696244% |
| C | 6176 | 56 | 0.906736% |
| D | 6176 | 1170 | 18.944301% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7491 | 6177 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7491 | 6177 | 14 | 14 | 0.19% | 0.23% |  |
| C | 7491 | 6177 | 6 | 6 | 0.08% | 0.10% |  |
| D | 7491 | 6177 | 1101 | 1101 | 14.70% | 17.82% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 80515 | 511.4 | 785 | 771 | 155.9 |
| A | 13 | 254 | 9490 | 55.92 | 785 | 771 | 155.9 |
| A | 0 | 226 | 6706 | 38.06 | 785 | 771 | 155.9 |
| B | 3 | 64 | 84962 | 571.18 | 793 | 776 | 147.4 |
| B | 0 | 230 | 68057 | 456.48 | 793 | 776 | 147.4 |
| B | 0 | 229 | 23513 | 154.26 | 793 | 776 | 147.4 |
| C | 9 | 54 | 193246 | 1086.71 | 762 | 770 | 177.1 |
| C | 14 | 238 | 122136 | 685.23 | 762 | 770 | 177.1 |
| C | 10 | 22 | 11778 | 62.15 | 762 | 770 | 177.1 |
| D | 7 | 238 | 3295611 | 19124.73 | 713 | 692 | 172.3 |
| D | 1 | 52 | 1040532 | 6035.55 | 713 | 692 | 172.3 |
| D | 14 | 35 | 106613 | 614.8 | 713 | 692 | 172.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
