| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_143T01_9000003208_21674cztM0_level2.evt | modeM0/AS1T03_143T01_9000003208_21674cztM0_level2_quad_clean.evt |
| Size (bytes) | 519,845,760 | 95,109,120 |
| Size | 495.8 MB | 90.7 MB |
| Events in quadrant A | 3,260,145 | 616,697 |
| Events in quadrant B | 3,681,149 | 619,340 |
| Events in quadrant C | 3,576,298 | 598,493 |
| Events in quadrant D | 4,760,014 | 567,201 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14083 | 1 |
| B | 0 | 15014 | 1 |
| C | 0 | 15135 | 1 |
| D | 0 | 18580 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6864 | 70 | 1.019814% |
| B | 6865 | 111 | 1.616897% |
| C | 6865 | 143 | 2.083030% |
| D | 6865 | 397 | 5.782957% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7169 | 6865 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7170 | 6866 | 19 | 19 | 0.26% | 0.28% |  |
| C | 7170 | 6866 | 6 | 6 | 0.08% | 0.09% |  |
| D | 7170 | 6866 | 253 | 253 | 3.53% | 3.68% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9847 | 52.8 | 845 | 828 | 170.8 |
| A | 0 | 226 | 7321 | 38.01 | 845 | 828 | 170.8 |
| A | 3 | 137 | 7097 | 36.7 | 845 | 828 | 170.8 |
| B | 3 | 64 | 124655 | 758.19 | 841 | 821 | 163.3 |
| B | 0 | 189 | 60167 | 363.35 | 841 | 821 | 163.3 |
| B | 0 | 229 | 54210 | 326.88 | 841 | 821 | 163.3 |
| C | 8 | 208 | 316990 | 1677.99 | 801 | 804 | 188.4 |
| C | 14 | 238 | 127042 | 669.94 | 801 | 804 | 188.4 |
| C | 13 | 61 | 5775 | 26.38 | 801 | 804 | 188.4 |
| D | 1 | 52 | 585039 | 2982.91 | 802 | 780 | 195.9 |
| D | 12 | 16 | 494886 | 2522.64 | 802 | 780 | 195.9 |
| D | 7 | 238 | 332082 | 1691.45 | 802 | 780 | 195.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
