| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_143T01_9000003208_21683cztM0_level2.evt | modeM0/AS1T03_143T01_9000003208_21683cztM0_level2_quad_clean.evt |
| Size (bytes) | 633,960,000 | 64,958,400 |
| Size | 604.6 MB | 61.9 MB |
| Events in quadrant A | 3,438,856 | 408,756 |
| Events in quadrant B | 3,649,876 | 418,156 |
| Events in quadrant C | 3,407,053 | 398,646 |
| Events in quadrant D | 8,275,031 | 298,506 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13645 | 2 |
| B | 0 | 14611 | 2 |
| C | 0 | 13619 | 2 |
| D | 0 | 29016 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6333 | 34 | 0.536870% |
| B | 6333 | 72 | 1.136902% |
| C | 6333 | 92 | 1.452708% |
| D | 6333 | 1553 | 24.522343% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7703 | 6334 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7703 | 6334 | 9 | 9 | 0.12% | 0.14% |  |
| C | 7703 | 6334 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7703 | 6333 | 1392 | 1392 | 18.07% | 21.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 88834 | 506.21 | 869 | 856 | 173.8 |
| A | 13 | 254 | 9490 | 49.68 | 869 | 856 | 173.8 |
| A | 0 | 226 | 7493 | 38.19 | 869 | 856 | 173.8 |
| B | 3 | 64 | 85753 | 523.62 | 875 | 859 | 162.1 |
| B | 0 | 229 | 52209 | 316.72 | 875 | 859 | 162.1 |
| B | 0 | 230 | 28241 | 168.89 | 875 | 859 | 162.1 |
| C | 14 | 238 | 137149 | 706.53 | 838 | 845 | 192.9 |
| C | 13 | 61 | 6062 | 27.04 | 838 | 845 | 192.9 |
| C | 3 | 202 | 2071 | 6.35 | 838 | 845 | 192.9 |
| D | 7 | 238 | 4984237 | 27486.75 | 750 | 730 | 181.3 |
| D | 2 | 136 | 83905 | 458.76 | 750 | 730 | 181.3 |
| D | 1 | 20 | 74473 | 406.73 | 750 | 730 | 181.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
