| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_010T04_9000003220_21725cztM0_level2.evt | modeM0/AS1A07_010T04_9000003220_21725cztM0_level2_quad_clean.evt |
| Size (bytes) | 644,103,360 | 111,251,520 |
| Size | 614.3 MB | 106.1 MB |
| Events in quadrant A | 4,141,080 | 741,489 |
| Events in quadrant B | 3,421,070 | 791,625 |
| Events in quadrant C | 3,265,568 | 754,928 |
| Events in quadrant D | 8,243,827 | 631,980 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16466 | 2 |
| B | 0 | 14297 | 2 |
| C | 0 | 13694 | 2 |
| D | 0 | 28924 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6441 | 461 | 7.157274% |
| B | 6441 | 63 | 0.978109% |
| C | 6441 | 69 | 1.071262% |
| D | 6442 | 1561 | 24.231605% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8951 | 6443 | 405 | 405 | 4.52% | 6.29% |  |
| B | 8951 | 6443 | 14 | 14 | 0.16% | 0.22% |  |
| C | 8951 | 6443 | 1 | 1 | 0.01% | 0.02% |  |
| D | 8952 | 6444 | 1500 | 1500 | 16.76% | 23.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 1006750 | 6433.51 | 787 | 771 | 156.4 |
| A | 5 | 16 | 84352 | 534.52 | 787 | 771 | 156.4 |
| A | 13 | 254 | 10621 | 62.99 | 787 | 771 | 156.4 |
| B | 3 | 64 | 90420 | 582.51 | 828 | 808 | 153.8 |
| B | 0 | 197 | 58350 | 374.04 | 828 | 808 | 153.8 |
| B | 0 | 189 | 21703 | 135.83 | 828 | 808 | 153.8 |
| C | 14 | 238 | 128961 | 690.16 | 799 | 806 | 185.7 |
| C | 8 | 208 | 9391 | 46.23 | 799 | 806 | 185.7 |
| C | 10 | 23 | 7611 | 36.65 | 799 | 806 | 185.7 |
| D | 12 | 235 | 5099852 | 29424.36 | 730 | 708 | 173.3 |
| D | 2 | 136 | 70473 | 402.58 | 730 | 708 | 173.3 |
| D | 1 | 52 | 63762 | 363.85 | 730 | 708 | 173.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
