| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_005T01_9000003224_21759cztM0_level2.evt | modeM0/AS1A07_005T01_9000003224_21759cztM0_level2_quad_clean.evt |
| Size (bytes) | 726,840,000 | 88,427,520 |
| Size | 693.2 MB | 84.3 MB |
| Events in quadrant A | 3,326,079 | 572,072 |
| Events in quadrant B | 3,504,585 | 587,649 |
| Events in quadrant C | 3,227,000 | 557,274 |
| Events in quadrant D | 11,496,967 | 488,376 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14490 | 1 |
| B | 0 | 14763 | 1 |
| C | 0 | 13947 | 1 |
| D | 0 | 38851 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6770 | 61 | 0.901034% |
| B | 6771 | 103 | 1.521193% |
| C | 6771 | 102 | 1.506424% |
| D | 6771 | 2460 | 36.331413% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7175 | 6771 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7176 | 6772 | 8 | 8 | 0.11% | 0.12% |  |
| C | 7176 | 6772 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7176 | 6772 | 2379 | 2379 | 33.15% | 35.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 127484 | 755.08 | 824 | 806 | 167.8 |
| A | 13 | 254 | 12886 | 72.0 | 824 | 806 | 167.8 |
| A | 4 | 2 | 11431 | 63.33 | 824 | 806 | 167.8 |
| B | 0 | 230 | 120414 | 747.82 | 828 | 807 | 159.9 |
| B | 3 | 64 | 63976 | 394.95 | 828 | 807 | 159.9 |
| B | 0 | 190 | 28954 | 175.98 | 828 | 807 | 159.9 |
| C | 14 | 238 | 124715 | 654.91 | 795 | 800 | 189.2 |
| C | 13 | 61 | 5545 | 25.08 | 795 | 800 | 189.2 |
| C | 1 | 0 | 2101 | 6.88 | 795 | 800 | 189.2 |
| D | 7 | 238 | 8012693 | 44763.53 | 732 | 711 | 179.0 |
| D | 1 | 52 | 597863 | 3336.33 | 732 | 711 | 179.0 |
| D | 13 | 153 | 40996 | 225.08 | 732 | 711 | 179.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
