| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_005T01_9000003224_21769cztM0_level2.evt | modeM0/AS1A07_005T01_9000003224_21769cztM0_level2_quad_clean.evt |
| Size (bytes) | 705,107,520 | 86,025,600 |
| Size | 672.4 MB | 82.0 MB |
| Events in quadrant A | 3,222,040 | 589,032 |
| Events in quadrant B | 3,511,927 | 605,257 |
| Events in quadrant C | 3,222,066 | 565,874 |
| Events in quadrant D | 10,991,771 | 424,287 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13414 | 2 |
| B | 0 | 14348 | 1 |
| C | 0 | 13307 | 1 |
| D | 0 | 36898 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6012 | 76 | 1.264138% |
| B | 6013 | 117 | 1.945784% |
| C | 6013 | 119 | 1.979045% |
| D | 6013 | 3016 | 50.157991% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7312 | 6013 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7313 | 6014 | 13 | 13 | 0.18% | 0.22% |  |
| C | 7313 | 6014 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7313 | 6014 | 2710 | 2710 | 37.06% | 45.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 19682 | 114.48 | 828 | 814 | 164.8 |
| A | 13 | 254 | 11892 | 67.21 | 828 | 814 | 164.8 |
| A | 15 | 174 | 7415 | 40.05 | 828 | 814 | 164.8 |
| B | 3 | 64 | 90110 | 573.57 | 834 | 816 | 155.7 |
| B | 5 | 172 | 46715 | 294.83 | 834 | 816 | 155.7 |
| B | 15 | 35 | 36227 | 227.46 | 834 | 816 | 155.7 |
| C | 14 | 238 | 126807 | 686.93 | 794 | 803 | 183.4 |
| C | 13 | 61 | 5514 | 25.68 | 794 | 803 | 183.4 |
| C | 14 | 111 | 1866 | 5.8 | 794 | 803 | 183.4 |
| D | 7 | 238 | 7729744 | 53958.74 | 594 | 578 | 143.2 |
| D | 7 | 223 | 744319 | 5192.19 | 594 | 578 | 143.2 |
| D | 13 | 104 | 73336 | 507.94 | 594 | 578 | 143.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
