| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_005T01_9000003224_21772cztM0_level2.evt | modeM0/AS1A07_005T01_9000003224_21772cztM0_level2_quad_clean.evt |
| Size (bytes) | 755,078,400 | 95,935,680 |
| Size | 720.1 MB | 91.5 MB |
| Events in quadrant A | 3,216,046 | 668,696 |
| Events in quadrant B | 3,646,693 | 690,513 |
| Events in quadrant C | 3,269,560 | 648,518 |
| Events in quadrant D | 12,285,132 | 432,422 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13844 | 2 |
| B | 0 | 15109 | 2 |
| C | 0 | 13823 | 2 |
| D | 0 | 41187 | 10 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6651 | 35 | 0.526237% |
| B | 6652 | 101 | 1.518340% |
| C | 6652 | 75 | 1.127480% |
| D | 6651 | 3500 | 52.623666% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7652 | 6653 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7652 | 6653 | 23 | 23 | 0.30% | 0.35% |  |
| C | 7652 | 6653 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7650 | 6651 | 2969 | 2969 | 38.81% | 44.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12633 | 70.01 | 831 | 813 | 168.8 |
| A | 0 | 226 | 7093 | 37.19 | 831 | 813 | 168.8 |
| A | 3 | 137 | 6672 | 34.7 | 831 | 813 | 168.8 |
| B | 3 | 64 | 150449 | 938.97 | 841 | 823 | 159.4 |
| B | 0 | 230 | 91433 | 568.62 | 841 | 823 | 159.4 |
| B | 0 | 197 | 42027 | 258.57 | 841 | 823 | 159.4 |
| C | 14 | 238 | 127024 | 669.56 | 804 | 810 | 188.5 |
| C | 13 | 61 | 5649 | 25.67 | 804 | 810 | 188.5 |
| C | 0 | 10 | 3245 | 12.91 | 804 | 810 | 188.5 |
| D | 7 | 238 | 9386987 | 63466.61 | 603 | 586 | 147.9 |
| D | 0 | 11 | 155108 | 1044.81 | 603 | 586 | 147.9 |
| D | 13 | 153 | 97768 | 657.1 | 603 | 586 | 147.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
