| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_006T02_9000003228_21798cztM0_level2.evt | modeM0/AS1A07_006T02_9000003228_21798cztM0_level2_quad_clean.evt |
| Size (bytes) | 640,512,000 | 92,926,080 |
| Size | 610.8 MB | 88.6 MB |
| Events in quadrant A | 3,267,827 | 616,832 |
| Events in quadrant B | 3,811,930 | 640,344 |
| Events in quadrant C | 3,199,747 | 603,697 |
| Events in quadrant D | 8,698,239 | 518,936 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13504 | 2 |
| B | 0 | 15136 | 2 |
| C | 0 | 13150 | 2 |
| D | 0 | 30006 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6216 | 13 | 0.209138% |
| B | 6216 | 185 | 2.976190% |
| C | 6216 | 49 | 0.788288% |
| D | 6216 | 1554 | 25.000000% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7562 | 6218 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7562 | 6218 | 120 | 120 | 1.59% | 1.93% |  |
| C | 7562 | 6218 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7562 | 6218 | 1479 | 1479 | 19.56% | 23.79% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 114649 | 688.0 | 816 | 802 | 165.5 |
| A | 13 | 254 | 12033 | 67.87 | 816 | 802 | 165.5 |
| A | 13 | 252 | 7777 | 42.15 | 816 | 802 | 165.5 |
| B | 3 | 64 | 417033 | 2733.59 | 818 | 802 | 152.3 |
| B | 4 | 216 | 51145 | 330.63 | 818 | 802 | 152.3 |
| B | 0 | 230 | 30710 | 196.42 | 818 | 802 | 152.3 |
| C | 14 | 238 | 126454 | 686.15 | 785 | 791 | 183.1 |
| C | 10 | 22 | 7231 | 35.16 | 785 | 791 | 183.1 |
| C | 0 | 10 | 7050 | 34.18 | 785 | 791 | 183.1 |
| D | 7 | 238 | 5480917 | 30576.73 | 732 | 711 | 179.2 |
| D | 7 | 38 | 275363 | 1532.42 | 732 | 711 | 179.2 |
| D | 15 | 145 | 48188 | 264.9 | 732 | 711 | 179.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
