| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_004T01_9000003230_21815cztM0_level2.evt | modeM0/AS1A07_004T01_9000003230_21815cztM0_level2_quad_clean.evt |
| Size (bytes) | 473,215,680 | 76,760,640 |
| Size | 451.3 MB | 73.2 MB |
| Events in quadrant A | 3,257,770 | 467,915 |
| Events in quadrant B | 3,525,664 | 480,545 |
| Events in quadrant C | 3,282,428 | 464,235 |
| Events in quadrant D | 3,809,399 | 443,493 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13806 | 2 |
| B | 0 | 14506 | 2 |
| C | 0 | 13754 | 2 |
| D | 0 | 15765 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6716 | 23 | 0.342466% |
| B | 6716 | 56 | 0.833830% |
| C | 6716 | 51 | 0.759381% |
| D | 6716 | 39 | 0.580703% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7851 | 6717 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7851 | 6717 | 17 | 17 | 0.22% | 0.25% |  |
| C | 7851 | 6717 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7851 | 6717 | 12 | 12 | 0.15% | 0.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 252 | 19630 | 112.23 | 835 | 819 | 167.6 |
| A | 13 | 254 | 12104 | 67.33 | 835 | 819 | 167.6 |
| A | 4 | 2 | 10083 | 55.27 | 835 | 819 | 167.6 |
| B | 3 | 64 | 83822 | 517.08 | 845 | 827 | 160.5 |
| B | 0 | 230 | 48193 | 295.1 | 845 | 827 | 160.5 |
| B | 15 | 33 | 18946 | 112.89 | 845 | 827 | 160.5 |
| C | 14 | 238 | 126832 | 671.28 | 808 | 815 | 187.7 |
| C | 13 | 61 | 5620 | 25.6 | 808 | 815 | 187.7 |
| C | 0 | 10 | 3901 | 16.44 | 808 | 815 | 187.7 |
| D | 1 | 52 | 567668 | 2888.72 | 809 | 785 | 196.2 |
| D | 13 | 153 | 68577 | 345.45 | 809 | 785 | 196.2 |
| D | 13 | 104 | 45541 | 228.07 | 809 | 785 | 196.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
