| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_004T01_9000003230_21850cztM0_level2.evt | modeM0/AS1A07_004T01_9000003230_21850cztM0_level2_quad_clean.evt |
| Size (bytes) | 937,624,320 | 170,519,040 |
| Size | 894.2 MB | 162.6 MB |
| Events in quadrant A | 6,061,876 | 1,082,660 |
| Events in quadrant B | 6,597,432 | 1,106,614 |
| Events in quadrant C | 6,037,542 | 1,073,540 |
| Events in quadrant D | 8,835,432 | 1,019,421 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 260 | 0 |
| B | 0 | 260 | 0 |
| C | 0 | 260 | 0 |
| D | 0 | 260 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26260 | 3 |
| B | 0 | 27442 | 3 |
| C | 0 | 26086 | 3 |
| D | 0 | 35212 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12766 | 167 | 1.308162% |
| B | 12766 | 242 | 1.895660% |
| C | 12766 | 206 | 1.613661% |
| D | 12766 | 485 | 3.799154% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14091 | 12766 | 11 | 11 | 0.08% | 0.09% |  |
| B | 14091 | 12766 | 57 | 57 | 0.40% | 0.45% |  |
| C | 14091 | 12767 | 0 | 0 | 0.00% | 0.00% |  |
| D | 14091 | 12766 | 240 | 240 | 1.70% | 1.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 108779 | 342.66 | 1541 | 1507 | 313.1 |
| A | 13 | 254 | 24789 | 74.37 | 1541 | 1507 | 313.1 |
| A | 0 | 226 | 13376 | 37.91 | 1541 | 1507 | 313.1 |
| B | 3 | 64 | 399797 | 1345.4 | 1535 | 1493 | 296.0 |
| B | 0 | 230 | 63225 | 208.52 | 1535 | 1493 | 296.0 |
| B | 0 | 190 | 63109 | 208.13 | 1535 | 1493 | 296.0 |
| C | 14 | 238 | 228863 | 656.18 | 1477 | 1488 | 346.5 |
| C | 4 | 175 | 31030 | 85.25 | 1477 | 1488 | 346.5 |
| C | 5 | 112 | 18547 | 49.23 | 1477 | 1488 | 346.5 |
| D | 1 | 52 | 1168193 | 3247.16 | 1482 | 1437 | 359.3 |
| D | 13 | 174 | 1068276 | 2969.08 | 1482 | 1437 | 359.3 |
| D | 7 | 238 | 430506 | 1194.13 | 1482 | 1437 | 359.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
