| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_118T01_9000003232_21860cztM0_level2.evt | modeM0/AS1A07_118T01_9000003232_21860cztM0_level2_quad_clean.evt |
| Size (bytes) | 562,988,160 | 84,075,840 |
| Size | 536.9 MB | 80.2 MB |
| Events in quadrant A | 3,595,985 | 520,735 |
| Events in quadrant B | 3,935,210 | 526,387 |
| Events in quadrant C | 3,539,285 | 516,548 |
| Events in quadrant D | 5,479,469 | 468,833 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15485 | 2 |
| B | 0 | 16341 | 2 |
| C | 0 | 15208 | 2 |
| D | 0 | 21370 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7370 | 72 | 0.976934% |
| B | 7370 | 171 | 2.320217% |
| C | 7370 | 104 | 1.411126% |
| D | 7370 | 708 | 9.606513% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7835 | 7371 | 6 | 6 | 0.08% | 0.08% |  |
| B | 7835 | 7371 | 57 | 57 | 0.73% | 0.77% |  |
| C | 7835 | 7371 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7835 | 7371 | 575 | 575 | 7.34% | 7.80% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 79624 | 429.86 | 900 | 880 | 183.2 |
| A | 4 | 2 | 38104 | 203.2 | 900 | 880 | 183.2 |
| A | 13 | 254 | 13728 | 70.14 | 900 | 880 | 183.2 |
| B | 3 | 64 | 259354 | 1480.01 | 902 | 878 | 174.6 |
| B | 0 | 230 | 46968 | 263.91 | 902 | 878 | 174.6 |
| B | 4 | 171 | 28465 | 157.96 | 902 | 878 | 174.6 |
| C | 14 | 238 | 135781 | 656.41 | 868 | 874 | 205.5 |
| C | 5 | 112 | 12545 | 56.79 | 868 | 874 | 205.5 |
| C | 13 | 61 | 6202 | 25.92 | 868 | 874 | 205.5 |
| D | 1 | 52 | 1897332 | 8635.24 | 825 | 805 | 219.6 |
| D | 7 | 38 | 312460 | 1419.02 | 825 | 805 | 219.6 |
| D | 2 | 234 | 30929 | 137.16 | 825 | 805 | 219.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
