| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_118T01_9000003232_21874cztM0_level2.evt | modeM0/AS1A07_118T01_9000003232_21874cztM0_level2_quad_clean.evt |
| Size (bytes) | 511,047,360 | 93,761,280 |
| Size | 487.4 MB | 89.4 MB |
| Events in quadrant A | 3,473,790 | 588,892 |
| Events in quadrant B | 3,740,485 | 602,800 |
| Events in quadrant C | 3,493,182 | 582,769 |
| Events in quadrant D | 4,278,783 | 561,563 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15031 | 2 |
| B | 0 | 15718 | 2 |
| C | 0 | 14969 | 3 |
| D | 0 | 17464 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7232 | 46 | 0.636062% |
| B | 7233 | 108 | 1.493156% |
| C | 7232 | 102 | 1.410398% |
| D | 7232 | 152 | 2.101770% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8972 | 7234 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8973 | 7235 | 28 | 28 | 0.31% | 0.39% |  |
| C | 8972 | 7234 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8972 | 7233 | 107 | 107 | 1.19% | 1.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 15480 | 80.38 | 895 | 877 | 181.7 |
| A | 13 | 254 | 13218 | 67.93 | 895 | 877 | 181.7 |
| A | 0 | 226 | 7794 | 38.07 | 895 | 877 | 181.7 |
| B | 3 | 64 | 135178 | 772.49 | 896 | 872 | 173.9 |
| B | 0 | 245 | 24224 | 134.31 | 896 | 872 | 173.9 |
| B | 0 | 230 | 20918 | 115.3 | 896 | 872 | 173.9 |
| C | 14 | 238 | 133495 | 655.62 | 862 | 867 | 202.3 |
| C | 13 | 61 | 5998 | 25.36 | 862 | 867 | 202.3 |
| C | 15 | 78 | 2060 | 5.9 | 862 | 867 | 202.3 |
| D | 1 | 52 | 438468 | 2069.68 | 863 | 839 | 211.4 |
| D | 7 | 238 | 229695 | 1082.33 | 863 | 839 | 211.4 |
| D | 12 | 227 | 206648 | 973.33 | 863 | 839 | 211.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
