| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_118T01_9000003232_21876cztM0_level2.evt | modeM0/AS1A07_118T01_9000003232_21876cztM0_level2_quad_clean.evt |
| Size (bytes) | 595,160,640 | 94,803,840 |
| Size | 567.6 MB | 90.4 MB |
| Events in quadrant A | 4,192,951 | 576,557 |
| Events in quadrant B | 4,352,370 | 587,526 |
| Events in quadrant C | 4,093,327 | 575,076 |
| Events in quadrant D | 4,819,738 | 551,841 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 172 | 0 |
| B | 0 | 172 | 0 |
| C | 0 | 172 | 0 |
| D | 0 | 172 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17996 | 2 |
| B | 0 | 18315 | 2 |
| C | 0 | 17579 | 2 |
| D | 0 | 20128 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8344 | 234 | 2.804410% |
| B | 8345 | 280 | 3.355303% |
| C | 8344 | 278 | 3.331735% |
| D | 8344 | 319 | 3.823106% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8814 | 8345 | 5 | 5 | 0.06% | 0.06% |  |
| B | 8815 | 8346 | 7 | 7 | 0.08% | 0.08% |  |
| C | 8814 | 8346 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8814 | 8345 | 107 | 107 | 1.21% | 1.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 171645 | 800.98 | 1041 | 1017 | 213.0 |
| A | 13 | 254 | 14692 | 64.19 | 1041 | 1017 | 213.0 |
| A | 3 | 137 | 8945 | 37.22 | 1041 | 1017 | 213.0 |
| B | 0 | 230 | 83829 | 404.15 | 1044 | 1013 | 204.9 |
| B | 3 | 64 | 63612 | 305.49 | 1044 | 1013 | 204.9 |
| B | 0 | 197 | 35178 | 166.73 | 1044 | 1013 | 204.9 |
| C | 14 | 238 | 155973 | 648.45 | 1006 | 1010 | 239.0 |
| C | 7 | 220 | 17469 | 68.87 | 1006 | 1010 | 239.0 |
| C | 13 | 61 | 6977 | 24.97 | 1006 | 1010 | 239.0 |
| D | 7 | 238 | 660295 | 2656.48 | 1009 | 982 | 248.2 |
| D | 2 | 136 | 218975 | 878.33 | 1009 | 982 | 248.2 |
| D | 1 | 52 | 50343 | 198.88 | 1009 | 982 | 248.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
