| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_041T01_9000003234_21888cztM0_level2.evt | modeM0/AS1A07_041T01_9000003234_21888cztM0_level2_quad_clean.evt |
| Size (bytes) | 503,631,360 | 95,783,040 |
| Size | 480.3 MB | 91.3 MB |
| Events in quadrant A | 3,147,297 | 618,580 |
| Events in quadrant B | 3,284,292 | 633,614 |
| Events in quadrant C | 3,127,263 | 610,682 |
| Events in quadrant D | 5,237,344 | 569,108 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13823 | 2 |
| B | 0 | 14103 | 2 |
| C | 0 | 13682 | 3 |
| D | 0 | 20159 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6716 | 21 | 0.312686% |
| B | 6716 | 31 | 0.461584% |
| C | 6715 | 49 | 0.729710% |
| D | 6715 | 459 | 6.835443% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7621 | 6717 | 7 | 7 | 0.09% | 0.10% |  |
| B | 7621 | 6717 | 5 | 5 | 0.07% | 0.07% |  |
| C | 7620 | 6716 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7620 | 6716 | 421 | 421 | 5.52% | 6.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 39781 | 243.26 | 798 | 780 | 160.3 |
| A | 5 | 16 | 15162 | 89.7 | 798 | 780 | 160.3 |
| A | 13 | 254 | 12450 | 72.79 | 798 | 780 | 160.3 |
| B | 3 | 64 | 25629 | 162.39 | 806 | 787 | 153.0 |
| B | 4 | 200 | 23836 | 150.67 | 806 | 787 | 153.0 |
| B | 4 | 171 | 18934 | 118.63 | 806 | 787 | 153.0 |
| C | 14 | 238 | 122164 | 679.66 | 768 | 773 | 178.6 |
| C | 0 | 10 | 10059 | 51.99 | 768 | 773 | 178.6 |
| C | 13 | 61 | 5438 | 26.12 | 768 | 773 | 178.6 |
| D | 7 | 238 | 1111804 | 6101.52 | 752 | 730 | 182.1 |
| D | 1 | 52 | 1005315 | 5516.73 | 752 | 730 | 182.1 |
| D | 13 | 174 | 145975 | 797.62 | 752 | 730 | 182.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
