| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_010T06_9000003238_21900cztM0_level2.evt | modeM0/AS1A07_010T06_9000003238_21900cztM0_level2_quad_clean.evt |
| Size (bytes) | 489,090,240 | 111,490,560 |
| Size | 466.4 MB | 106.3 MB |
| Events in quadrant A | 3,233,867 | 763,078 |
| Events in quadrant B | 3,326,395 | 779,147 |
| Events in quadrant C | 3,159,747 | 725,310 |
| Events in quadrant D | 4,688,300 | 693,467 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13447 | 1 |
| B | 0 | 13743 | 1 |
| C | 0 | 13088 | 2 |
| D | 0 | 17998 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5948 | 93 | 1.563551% |
| B | 5949 | 89 | 1.496050% |
| C | 5948 | 92 | 1.546738% |
| D | 5948 | 573 | 9.633490% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7303 | 5948 | 12 | 12 | 0.16% | 0.20% |  |
| B | 7304 | 5949 | 4 | 4 | 0.05% | 0.07% |  |
| C | 7303 | 5948 | 4 | 4 | 0.05% | 0.07% |  |
| D | 7303 | 5948 | 452 | 452 | 6.19% | 7.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 92892 | 579.77 | 806 | 792 | 158.9 |
| A | 5 | 16 | 30027 | 184.03 | 806 | 792 | 158.9 |
| A | 13 | 254 | 10940 | 63.88 | 806 | 792 | 158.9 |
| B | 3 | 64 | 49744 | 328.63 | 808 | 792 | 149.0 |
| B | 4 | 173 | 43649 | 287.71 | 808 | 792 | 149.0 |
| B | 0 | 190 | 29230 | 190.91 | 808 | 792 | 149.0 |
| C | 14 | 238 | 124014 | 708.45 | 760 | 766 | 174.0 |
| C | 10 | 22 | 66440 | 377.51 | 760 | 766 | 174.0 |
| C | 13 | 61 | 5533 | 27.4 | 760 | 766 | 174.0 |
| D | 7 | 238 | 1506949 | 8616.81 | 734 | 716 | 174.8 |
| D | 12 | 227 | 241478 | 1377.34 | 734 | 716 | 174.8 |
| D | 1 | 52 | 42003 | 236.19 | 734 | 716 | 174.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
