| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_010T11_9000003240_21905cztM0_level2.evt | modeM0/AS1A07_010T11_9000003240_21905cztM0_level2_quad_clean.evt |
| Size (bytes) | 513,532,800 | 114,275,520 |
| Size | 489.7 MB | 109.0 MB |
| Events in quadrant A | 3,422,796 | 751,785 |
| Events in quadrant B | 3,900,272 | 758,846 |
| Events in quadrant C | 3,586,035 | 722,852 |
| Events in quadrant D | 4,129,436 | 701,100 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15372 | 1 |
| B | 0 | 16555 | 1 |
| C | 0 | 15632 | 1 |
| D | 0 | 17470 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7568 | 47 | 0.621036% |
| B | 7568 | 202 | 2.669133% |
| C | 7569 | 132 | 1.743956% |
| D | 7569 | 119 | 1.572202% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7738 | 7569 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7738 | 7569 | 108 | 108 | 1.40% | 1.43% |  |
| C | 7739 | 7570 | 5 | 5 | 0.06% | 0.07% |  |
| D | 7739 | 7570 | 57 | 57 | 0.74% | 0.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 13124 | 69.0 | 882 | 863 | 177.7 |
| A | 5 | 16 | 11608 | 60.47 | 882 | 863 | 177.7 |
| A | 3 | 137 | 7516 | 37.44 | 882 | 863 | 177.7 |
| B | 3 | 64 | 378892 | 2235.09 | 884 | 860 | 169.1 |
| B | 4 | 173 | 20853 | 118.21 | 884 | 860 | 169.1 |
| B | 12 | 111 | 20316 | 115.03 | 884 | 860 | 169.1 |
| C | 14 | 238 | 134594 | 667.96 | 855 | 858 | 200.2 |
| C | 10 | 22 | 97049 | 480.44 | 855 | 858 | 200.2 |
| C | 8 | 128 | 9257 | 41.95 | 855 | 858 | 200.2 |
| D | 7 | 238 | 395321 | 1883.19 | 859 | 832 | 209.5 |
| D | 13 | 174 | 169019 | 802.88 | 859 | 832 | 209.5 |
| D | 2 | 136 | 95272 | 450.83 | 859 | 832 | 209.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
