| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_100T03_9000003242_21934cztM0_level2.evt | modeM0/AS1A07_100T03_9000003242_21934cztM0_level2_quad_clean.evt |
| Size (bytes) | 722,148,480 | 150,871,680 |
| Size | 688.7 MB | 143.9 MB |
| Events in quadrant A | 4,407,803 | 1,029,160 |
| Events in quadrant B | 4,196,720 | 1,049,168 |
| Events in quadrant C | 3,881,451 | 1,029,136 |
| Events in quadrant D | 8,827,362 | 889,889 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18765 | 1 |
| B | 0 | 17990 | 1 |
| C | 0 | 17179 | 1 |
| D | 0 | 32028 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 172 | 0 |
| B | 0 | 172 | 0 |
| C | 0 | 172 | 0 |
| D | 0 | 172 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8227 | 220 | 2.674122% |
| B | 8228 | 190 | 2.309188% |
| C | 8228 | 138 | 1.677200% |
| D | 8228 | 1537 | 18.680117% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8717 | 8230 | 143 | 143 | 1.64% | 1.74% |  |
| B | 8718 | 8230 | 61 | 61 | 0.70% | 0.74% |  |
| C | 8718 | 8231 | 2 | 2 | 0.02% | 0.02% |  |
| D | 8718 | 8228 | 1275 | 1275 | 14.62% | 15.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 636860 | 3214.16 | 976 | 952 | 197.8 |
| A | 13 | 254 | 14634 | 69.15 | 976 | 952 | 197.8 |
| A | 0 | 226 | 8369 | 37.49 | 976 | 952 | 197.8 |
| B | 3 | 64 | 270528 | 1443.62 | 981 | 954 | 186.7 |
| B | 12 | 111 | 22695 | 116.43 | 981 | 954 | 186.7 |
| B | 11 | 111 | 19664 | 100.2 | 981 | 954 | 186.7 |
| C | 14 | 238 | 148792 | 664.78 | 954 | 959 | 222.4 |
| C | 9 | 54 | 13059 | 54.41 | 954 | 959 | 222.4 |
| C | 13 | 61 | 6823 | 26.37 | 954 | 959 | 222.4 |
| D | 12 | 235 | 2830944 | 13544.42 | 862 | 835 | 209.0 |
| D | 7 | 238 | 1438807 | 6881.89 | 862 | 835 | 209.0 |
| D | 1 | 52 | 950792 | 4546.33 | 862 | 835 | 209.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
