| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_130T01_9000003246_21967cztM0_level2.evt | modeM0/AS1A07_130T01_9000003246_21967cztM0_level2_quad_clean.evt |
| Size (bytes) | 513,607,680 | 86,045,760 |
| Size | 489.8 MB | 82.1 MB |
| Events in quadrant A | 3,613,683 | 525,354 |
| Events in quadrant B | 3,809,403 | 538,877 |
| Events in quadrant C | 3,655,320 | 517,146 |
| Events in quadrant D | 3,968,380 | 503,925 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15380 | 2 |
| B | 0 | 15814 | 2 |
| C | 0 | 15388 | 3 |
| D | 0 | 16710 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7482 | 102 | 1.363272% |
| B | 7483 | 142 | 1.897635% |
| C | 7482 | 122 | 1.630580% |
| D | 7482 | 156 | 2.085004% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9152 | 7482 | 2 | 2 | 0.02% | 0.03% |  |
| B | 9153 | 7483 | 15 | 15 | 0.16% | 0.20% |  |
| C | 9152 | 7482 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9152 | 7482 | 70 | 70 | 0.76% | 0.94% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 13180 | 65.03 | 932 | 910 | 188.7 |
| A | 10 | 253 | 12540 | 61.64 | 932 | 910 | 188.7 |
| A | 0 | 226 | 8067 | 37.93 | 932 | 910 | 188.7 |
| B | 3 | 64 | 98111 | 543.3 | 931 | 907 | 178.9 |
| B | 0 | 197 | 45615 | 249.89 | 931 | 907 | 178.9 |
| B | 12 | 111 | 22589 | 121.19 | 931 | 907 | 178.9 |
| C | 14 | 238 | 139912 | 656.89 | 898 | 901 | 211.6 |
| C | 8 | 78 | 6674 | 27.28 | 898 | 901 | 211.6 |
| C | 13 | 61 | 6181 | 24.95 | 898 | 901 | 211.6 |
| D | 13 | 174 | 215803 | 975.39 | 906 | 879 | 220.3 |
| D | 2 | 136 | 102918 | 463.08 | 906 | 879 | 220.3 |
| D | 1 | 52 | 52154 | 232.7 | 906 | 879 | 220.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
