| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_153T02_9000003250_22010cztM0_level2.evt | modeM0/AS1A07_153T02_9000003250_22010cztM0_level2_quad_clean.evt |
| Size (bytes) | 877,017,600 | 152,524,800 |
| Size | 836.4 MB | 145.5 MB |
| Events in quadrant A | 5,588,770 | 975,869 |
| Events in quadrant B | 5,788,550 | 998,398 |
| Events in quadrant C | 5,444,876 | 945,539 |
| Events in quadrant D | 8,962,201 | 905,553 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 234 | 0 |
| B | 0 | 234 | 0 |
| C | 0 | 234 | 0 |
| D | 0 | 234 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24091 | 2 |
| B | 0 | 24399 | 2 |
| C | 0 | 23308 | 2 |
| D | 0 | 34308 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 11475 | 57 | 0.496732% |
| B | 11474 | 91 | 0.793097% |
| C | 11474 | 148 | 1.289873% |
| D | 11475 | 752 | 6.553377% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 13010 | 11476 | 1 | 1 | 0.01% | 0.01% |  |
| B | 13009 | 11474 | 11 | 11 | 0.08% | 0.10% |  |
| C | 13009 | 11474 | 0 | 0 | 0.00% | 0.00% |  |
| D | 13009 | 11475 | 635 | 635 | 4.88% | 5.53% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 273533 | 992.54 | 1376 | 1348 | 274.2 |
| A | 13 | 254 | 18479 | 62.47 | 1376 | 1348 | 274.2 |
| A | 3 | 137 | 11829 | 38.22 | 1376 | 1348 | 274.2 |
| B | 0 | 230 | 275841 | 1060.4 | 1372 | 1338 | 258.9 |
| B | 3 | 64 | 88869 | 338.13 | 1372 | 1338 | 258.9 |
| B | 12 | 111 | 31770 | 117.56 | 1372 | 1338 | 258.9 |
| C | 14 | 238 | 211243 | 673.89 | 1333 | 1338 | 311.5 |
| C | 10 | 91 | 16802 | 49.64 | 1333 | 1338 | 311.5 |
| C | 0 | 239 | 16499 | 48.67 | 1333 | 1338 | 311.5 |
| D | 1 | 52 | 1904396 | 5959.67 | 1321 | 1285 | 319.3 |
| D | 7 | 238 | 1491752 | 4667.46 | 1321 | 1285 | 319.3 |
| D | 12 | 227 | 260091 | 810.46 | 1321 | 1285 | 319.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
