| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_091T07_9000003254_22027cztM0_level2.evt | modeM0/AS1A07_091T07_9000003254_22027cztM0_level2_quad_clean.evt |
| Size (bytes) | 486,676,800 | 101,085,120 |
| Size | 464.1 MB | 96.4 MB |
| Events in quadrant A | 3,236,560 | 664,459 |
| Events in quadrant B | 3,326,607 | 668,881 |
| Events in quadrant C | 3,212,011 | 642,629 |
| Events in quadrant D | 4,511,653 | 621,228 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13708 | 2 |
| B | 0 | 13998 | 2 |
| C | 0 | 13775 | 2 |
| D | 0 | 17891 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6654 | 32 | 0.480914% |
| B | 6654 | 49 | 0.736399% |
| C | 6654 | 64 | 0.961827% |
| D | 6654 | 440 | 6.612564% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7709 | 6654 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7709 | 6654 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7709 | 6654 | 11 | 11 | 0.14% | 0.17% |  |
| D | 7708 | 6653 | 411 | 411 | 5.33% | 6.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 66433 | 399.59 | 821 | 804 | 164.2 |
| A | 13 | 254 | 10721 | 60.38 | 821 | 804 | 164.2 |
| A | 0 | 226 | 7100 | 38.33 | 821 | 804 | 164.2 |
| B | 0 | 230 | 69901 | 447.84 | 809 | 791 | 154.3 |
| B | 3 | 64 | 45359 | 288.8 | 809 | 791 | 154.3 |
| B | 12 | 111 | 18546 | 115.05 | 809 | 791 | 154.3 |
| C | 14 | 238 | 122972 | 675.78 | 773 | 777 | 180.8 |
| C | 10 | 22 | 71034 | 388.54 | 773 | 777 | 180.8 |
| C | 13 | 61 | 5423 | 25.69 | 773 | 777 | 180.8 |
| D | 1 | 52 | 1205193 | 6422.11 | 772 | 748 | 187.5 |
| D | 2 | 136 | 219275 | 1165.19 | 772 | 748 | 187.5 |
| D | 11 | 176 | 81043 | 428.13 | 772 | 748 | 187.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
