| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_091T07_9000003254_22030cztM0_level2.evt | modeM0/AS1A07_091T07_9000003254_22030cztM0_level2_quad_clean.evt |
| Size (bytes) | 575,916,480 | 89,879,040 |
| Size | 549.2 MB | 85.7 MB |
| Events in quadrant A | 3,497,958 | 580,601 |
| Events in quadrant B | 3,615,033 | 583,762 |
| Events in quadrant C | 3,488,278 | 563,253 |
| Events in quadrant D | 6,397,895 | 538,879 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14427 | 2 |
| B | 0 | 14738 | 2 |
| C | 0 | 14190 | 2 |
| D | 0 | 23383 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6524 | 85 | 1.302882% |
| B | 6524 | 92 | 1.410178% |
| C | 6524 | 116 | 1.778050% |
| D | 6524 | 1074 | 16.462293% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7864 | 6524 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7864 | 6524 | 11 | 11 | 0.14% | 0.17% |  |
| C | 7864 | 6524 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7864 | 6524 | 975 | 975 | 12.40% | 14.94% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10428 | 53.51 | 905 | 889 | 178.3 |
| A | 0 | 226 | 8191 | 40.96 | 905 | 889 | 178.3 |
| A | 3 | 137 | 6939 | 33.94 | 905 | 889 | 178.3 |
| B | 3 | 64 | 77665 | 473.8 | 883 | 864 | 162.1 |
| B | 0 | 230 | 36940 | 222.56 | 883 | 864 | 162.1 |
| B | 0 | 190 | 33490 | 201.28 | 883 | 864 | 162.1 |
| C | 14 | 238 | 138449 | 707.76 | 855 | 862 | 194.4 |
| C | 0 | 10 | 13524 | 65.13 | 855 | 862 | 194.4 |
| C | 13 | 61 | 5945 | 26.15 | 855 | 862 | 194.4 |
| D | 1 | 52 | 2617327 | 13212.72 | 817 | 794 | 198.0 |
| D | 5 | 222 | 362715 | 1827.59 | 817 | 794 | 198.0 |
| D | 11 | 176 | 203695 | 1024.59 | 817 | 794 | 198.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
