| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_134T01_9000003256_22036cztM0_level2.evt | modeM0/AS1A07_134T01_9000003256_22036cztM0_level2_quad_clean.evt |
| Size (bytes) | 546,569,280 | 105,295,680 |
| Size | 521.2 MB | 100.4 MB |
| Events in quadrant A | 3,524,490 | 685,345 |
| Events in quadrant B | 3,780,093 | 690,401 |
| Events in quadrant C | 3,554,381 | 659,897 |
| Events in quadrant D | 5,179,527 | 625,887 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15528 | 1 |
| B | 0 | 16167 | 1 |
| C | 0 | 15484 | 1 |
| D | 0 | 20556 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7584 | 35 | 0.461498% |
| B | 7584 | 87 | 1.147152% |
| C | 7584 | 76 | 1.002110% |
| D | 7584 | 528 | 6.962025% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7944 | 7586 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7944 | 7585 | 12 | 12 | 0.15% | 0.16% |  |
| C | 7944 | 7585 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7944 | 7584 | 427 | 427 | 5.38% | 5.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12139 | 61.08 | 912 | 891 | 184.1 |
| A | 3 | 137 | 8105 | 39.18 | 912 | 891 | 184.1 |
| A | 0 | 226 | 7812 | 37.59 | 912 | 891 | 184.1 |
| B | 3 | 64 | 121201 | 693.42 | 907 | 884 | 173.5 |
| B | 0 | 197 | 42374 | 239.12 | 907 | 884 | 173.5 |
| B | 12 | 111 | 21718 | 120.07 | 907 | 884 | 173.5 |
| C | 14 | 238 | 136248 | 663.22 | 869 | 872 | 204.1 |
| C | 8 | 128 | 17758 | 82.73 | 869 | 872 | 204.1 |
| C | 8 | 112 | 8286 | 36.32 | 869 | 872 | 204.1 |
| D | 11 | 176 | 919566 | 4397.99 | 853 | 827 | 208.9 |
| D | 1 | 52 | 664708 | 3177.99 | 853 | 827 | 208.9 |
| D | 5 | 222 | 163493 | 778.68 | 853 | 827 | 208.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
