| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_007T04_9000003276_22119cztM0_level2.evt | modeM0/AS1A07_007T04_9000003276_22119cztM0_level2_quad_clean.evt |
| Size (bytes) | 483,071,040 | 103,852,800 |
| Size | 460.7 MB | 99.0 MB |
| Events in quadrant A | 3,363,181 | 691,195 |
| Events in quadrant B | 3,539,080 | 693,785 |
| Events in quadrant C | 3,393,055 | 655,463 |
| Events in quadrant D | 3,884,405 | 642,812 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13858 | 1 |
| B | 0 | 14438 | 1 |
| C | 0 | 13956 | 1 |
| D | 0 | 15847 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6628 | 118 | 1.780326% |
| B | 6629 | 164 | 2.473978% |
| C | 6629 | 137 | 2.066677% |
| D | 6629 | 124 | 1.870569% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7688 | 6629 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7689 | 6630 | 25 | 25 | 0.33% | 0.38% |  |
| C | 7689 | 6630 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7689 | 6630 | 38 | 38 | 0.49% | 0.57% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12089 | 64.88 | 869 | 853 | 173.2 |
| A | 5 | 16 | 11200 | 59.75 | 869 | 853 | 173.2 |
| A | 0 | 226 | 7490 | 38.33 | 869 | 853 | 173.2 |
| B | 3 | 64 | 163171 | 1008.15 | 852 | 832 | 161.0 |
| B | 0 | 197 | 19272 | 114.51 | 852 | 832 | 161.0 |
| B | 12 | 111 | 19111 | 113.51 | 852 | 832 | 161.0 |
| C | 14 | 238 | 131268 | 689.41 | 820 | 826 | 189.2 |
| C | 10 | 22 | 44390 | 230.24 | 820 | 826 | 189.2 |
| C | 3 | 233 | 17920 | 90.35 | 820 | 826 | 189.2 |
| D | 2 | 133 | 301623 | 1493.97 | 838 | 815 | 201.3 |
| D | 11 | 176 | 255807 | 1266.42 | 838 | 815 | 201.3 |
| D | 13 | 172 | 54481 | 266.53 | 838 | 815 | 201.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
