| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_007T04_9000003272_22122cztM0_level2.evt | modeM0/AS1A07_007T04_9000003272_22122cztM0_level2_quad_clean.evt |
| Size (bytes) | 541,180,800 | 107,291,520 |
| Size | 516.1 MB | 102.3 MB |
| Events in quadrant A | 3,665,123 | 700,410 |
| Events in quadrant B | 3,905,563 | 701,742 |
| Events in quadrant C | 3,666,864 | 674,996 |
| Events in quadrant D | 4,645,736 | 652,934 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15837 | 2 |
| B | 0 | 16426 | 2 |
| C | 0 | 15781 | 2 |
| D | 0 | 18637 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7459 | 98 | 1.313849% |
| B | 7459 | 172 | 2.305939% |
| C | 7458 | 124 | 1.662644% |
| D | 7458 | 152 | 2.038080% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7759 | 7460 | 30 | 30 | 0.39% | 0.40% |  |
| B | 7759 | 7460 | 68 | 68 | 0.88% | 0.91% |  |
| C | 7758 | 7459 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7758 | 7459 | 111 | 111 | 1.43% | 1.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 105142 | 560.88 | 922 | 900 | 185.9 |
| A | 13 | 254 | 14537 | 73.37 | 922 | 900 | 185.9 |
| A | 3 | 137 | 8154 | 39.03 | 922 | 900 | 185.9 |
| B | 3 | 64 | 152251 | 865.26 | 909 | 885 | 174.9 |
| B | 10 | 246 | 151604 | 861.56 | 909 | 885 | 174.9 |
| B | 0 | 190 | 27004 | 149.3 | 909 | 885 | 174.9 |
| C | 14 | 238 | 138379 | 663.17 | 882 | 889 | 207.3 |
| C | 10 | 22 | 75889 | 361.76 | 882 | 889 | 207.3 |
| C | 9 | 54 | 10363 | 45.7 | 882 | 889 | 207.3 |
| D | 7 | 238 | 605724 | 2772.66 | 894 | 867 | 218.2 |
| D | 1 | 52 | 178395 | 813.79 | 894 | 867 | 218.2 |
| D | 7 | 223 | 173772 | 792.59 | 894 | 867 | 218.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
