| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_145T01_9000003278_22130cztM0_level2.evt | modeM0/AS1T03_145T01_9000003278_22130cztM0_level2_quad_clean.evt |
| Size (bytes) | 505,031,040 | 68,811,840 |
| Size | 481.6 MB | 65.6 MB |
| Events in quadrant A | 3,299,235 | 417,375 |
| Events in quadrant B | 3,505,561 | 425,475 |
| Events in quadrant C | 3,430,891 | 410,497 |
| Events in quadrant D | 4,634,640 | 393,013 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13619 | 2 |
| B | 0 | 14267 | 2 |
| C | 0 | 14178 | 2 |
| D | 0 | 17880 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6267 | 70 | 1.116962% |
| B | 6266 | 109 | 1.739547% |
| C | 6266 | 135 | 2.154485% |
| D | 6266 | 294 | 4.691989% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7502 | 6268 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7501 | 6267 | 27 | 27 | 0.36% | 0.43% |  |
| C | 7501 | 6267 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7501 | 6267 | 196 | 196 | 2.61% | 3.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10812 | 59.21 | 855 | 839 | 168.4 |
| A | 0 | 226 | 7181 | 37.65 | 855 | 839 | 168.4 |
| A | 3 | 137 | 6710 | 34.86 | 855 | 839 | 168.4 |
| B | 3 | 64 | 127615 | 809.86 | 852 | 835 | 156.5 |
| B | 11 | 51 | 21862 | 134.32 | 852 | 835 | 156.5 |
| B | 12 | 111 | 18605 | 113.51 | 852 | 835 | 156.5 |
| C | 14 | 238 | 134140 | 700.16 | 831 | 842 | 190.4 |
| C | 10 | 22 | 40266 | 207.08 | 831 | 842 | 190.4 |
| C | 9 | 54 | 13312 | 65.5 | 831 | 842 | 190.4 |
| D | 5 | 222 | 394630 | 1995.67 | 829 | 807 | 197.3 |
| D | 13 | 104 | 391509 | 1979.85 | 829 | 807 | 197.3 |
| D | 1 | 52 | 341594 | 1726.91 | 829 | 807 | 197.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
