| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_007T03_9000003280_22173cztM0_level2.evt | modeM0/AS1A07_007T03_9000003280_22173cztM0_level2_quad_clean.evt |
| Size (bytes) | 433,788,480 | 83,597,760 |
| Size | 413.7 MB | 79.7 MB |
| Events in quadrant A | 3,142,256 | 535,104 |
| Events in quadrant B | 3,201,216 | 548,405 |
| Events in quadrant C | 3,169,683 | 513,062 |
| Events in quadrant D | 3,193,504 | 493,041 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13184 | 2 |
| B | 0 | 13327 | 2 |
| C | 0 | 13240 | 2 |
| D | 0 | 13654 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6335 | 15 | 0.236780% |
| B | 6335 | 28 | 0.441989% |
| C | 6335 | 45 | 0.710339% |
| D | 6335 | 80 | 1.262826% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7595 | 6336 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7595 | 6336 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7595 | 6336 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7595 | 6336 | 67 | 67 | 0.88% | 1.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11348 | 64.5 | 814 | 799 | 163.6 |
| A | 0 | 226 | 7091 | 38.47 | 814 | 799 | 163.6 |
| A | 3 | 137 | 6540 | 35.1 | 814 | 799 | 163.6 |
| B | 12 | 111 | 18061 | 113.89 | 814 | 796 | 151.6 |
| B | 11 | 111 | 16037 | 100.53 | 814 | 796 | 151.6 |
| B | 14 | 111 | 14450 | 90.07 | 814 | 796 | 151.6 |
| C | 14 | 238 | 127081 | 702.35 | 777 | 786 | 179.8 |
| C | 0 | 10 | 7807 | 39.05 | 777 | 786 | 179.8 |
| C | 13 | 61 | 5467 | 26.03 | 777 | 786 | 179.8 |
| D | 1 | 52 | 225526 | 1197.06 | 774 | 752 | 187.8 |
| D | 2 | 234 | 25206 | 130.23 | 774 | 752 | 187.8 |
| D | 2 | 136 | 16693 | 84.9 | 774 | 752 | 187.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
