| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_134T02_9000003282_22178cztM0_level2.evt | modeM0/AS1A07_134T02_9000003282_22178cztM0_level2_quad_clean.evt |
| Size (bytes) | 200,088,000 | 27,457,920 |
| Size | 190.8 MB | 26.2 MB |
| Events in quadrant A | 1,458,356 | 161,764 |
| Events in quadrant B | 1,506,763 | 163,129 |
| Events in quadrant C | 1,444,527 | 153,359 |
| Events in quadrant D | 1,460,452 | 155,242 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 56 | 0 |
| B | 0 | 56 | 0 |
| C | 0 | 56 | 0 |
| D | 0 | 56 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5937 | 1 |
| B | 0 | 6035 | 1 |
| C | 0 | 5934 | 1 |
| D | 0 | 6049 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2762 | 111 | 4.018827% |
| B | 2762 | 125 | 4.525706% |
| C | 2762 | 141 | 5.104996% |
| D | 2762 | 106 | 3.837799% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3412 | 2763 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3412 | 2763 | 0 | 0 | 0.00% | 0.00% |  |
| C | 3412 | 2763 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3412 | 2763 | 2 | 2 | 0.06% | 0.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 5058 | 59.99 | 377 | 369 | 78.2 |
| A | 3 | 137 | 3436 | 39.24 | 377 | 369 | 78.2 |
| A | 0 | 226 | 3221 | 36.49 | 377 | 369 | 78.2 |
| B | 0 | 190 | 31742 | 418.86 | 370 | 359 | 74.9 |
| B | 0 | 219 | 16345 | 213.36 | 370 | 359 | 74.9 |
| B | 12 | 111 | 8988 | 115.17 | 370 | 359 | 74.9 |
| C | 14 | 238 | 54706 | 631.23 | 356 | 357 | 86.1 |
| C | 13 | 61 | 2509 | 24.99 | 356 | 357 | 86.1 |
| C | 15 | 78 | 877 | 6.04 | 356 | 357 | 86.1 |
| D | 1 | 52 | 23583 | 249.52 | 369 | 357 | 93.1 |
| D | 13 | 172 | 16096 | 169.09 | 369 | 357 | 93.1 |
| D | 2 | 234 | 12328 | 128.61 | 369 | 357 | 93.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
