| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_018T02_9000003288_22230cztM0_level2.evt | modeM0/AS1A07_018T02_9000003288_22230cztM0_level2_quad_clean.evt |
| Size (bytes) | 454,821,120 | 75,260,160 |
| Size | 433.8 MB | 71.8 MB |
| Events in quadrant A | 3,243,578 | 462,664 |
| Events in quadrant B | 3,378,010 | 475,949 |
| Events in quadrant C | 3,285,880 | 445,883 |
| Events in quadrant D | 3,417,198 | 432,796 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13752 | 2 |
| B | 0 | 14076 | 2 |
| C | 0 | 13871 | 2 |
| D | 0 | 14656 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6620 | 22 | 0.332326% |
| B | 6620 | 45 | 0.679758% |
| C | 6620 | 61 | 0.921450% |
| D | 6619 | 26 | 0.392809% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7780 | 6621 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7780 | 6621 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7780 | 6621 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7779 | 6620 | 1 | 1 | 0.01% | 0.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10685 | 58.54 | 839 | 822 | 168.5 |
| A | 4 | 2 | 7233 | 38.05 | 839 | 822 | 168.5 |
| A | 0 | 226 | 7170 | 37.68 | 839 | 822 | 168.5 |
| B | 4 | 173 | 41102 | 251.3 | 843 | 823 | 160.3 |
| B | 0 | 219 | 26765 | 161.85 | 843 | 823 | 160.3 |
| B | 12 | 111 | 19368 | 115.7 | 843 | 823 | 160.3 |
| C | 14 | 238 | 129743 | 687.36 | 805 | 812 | 187.6 |
| C | 0 | 10 | 15221 | 76.82 | 805 | 812 | 187.6 |
| C | 13 | 61 | 5566 | 25.34 | 805 | 812 | 187.6 |
| D | 2 | 16 | 305356 | 1549.95 | 809 | 786 | 196.5 |
| D | 2 | 234 | 24076 | 118.52 | 809 | 786 | 196.5 |
| D | 12 | 227 | 22658 | 111.31 | 809 | 786 | 196.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
