| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_018T07_9000003294_22262cztM0_level2.evt | modeM0/AS1A07_018T07_9000003294_22262cztM0_level2_quad_clean.evt |
| Size (bytes) | 538,231,680 | 69,448,320 |
| Size | 513.3 MB | 66.2 MB |
| Events in quadrant A | 3,301,682 | 434,676 |
| Events in quadrant B | 3,571,210 | 443,071 |
| Events in quadrant C | 3,744,748 | 404,413 |
| Events in quadrant D | 5,267,889 | 393,420 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13319 | 1 |
| B | 0 | 14381 | 1 |
| C | 0 | 14766 | 1 |
| D | 0 | 19525 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6119 | 68 | 1.111293% |
| B | 6119 | 131 | 2.140873% |
| C | 6119 | 294 | 4.804707% |
| D | 6118 | 735 | 12.013730% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7464 | 6120 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7464 | 6120 | 4 | 4 | 0.05% | 0.07% |  |
| C | 7464 | 6120 | 173 | 173 | 2.32% | 2.83% |  |
| D | 7463 | 6119 | 572 | 572 | 7.66% | 9.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9212 | 49.05 | 857 | 842 | 170.6 |
| A | 0 | 226 | 7353 | 38.16 | 857 | 842 | 170.6 |
| A | 3 | 137 | 6776 | 34.78 | 857 | 842 | 170.6 |
| B | 3 | 64 | 222336 | 1401.0 | 850 | 831 | 158.1 |
| B | 4 | 171 | 30813 | 189.63 | 850 | 831 | 158.1 |
| B | 12 | 111 | 18722 | 113.16 | 850 | 831 | 158.1 |
| C | 10 | 22 | 488090 | 2645.93 | 800 | 807 | 184.2 |
| C | 14 | 238 | 130177 | 702.48 | 800 | 807 | 184.2 |
| C | 13 | 61 | 5613 | 26.1 | 800 | 807 | 184.2 |
| D | 1 | 52 | 2184185 | 11493.18 | 792 | 771 | 190.0 |
| D | 2 | 136 | 36626 | 188.74 | 792 | 771 | 190.0 |
| D | 2 | 120 | 33542 | 172.5 | 792 | 771 | 190.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
