| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_018T08_9000003296_22277cztM0_level2.evt | modeM0/AS1A07_018T08_9000003296_22277cztM0_level2_quad_clean.evt |
| Size (bytes) | 474,050,880 | 71,565,120 |
| Size | 452.1 MB | 68.2 MB |
| Events in quadrant A | 3,197,685 | 455,131 |
| Events in quadrant B | 3,332,230 | 463,832 |
| Events in quadrant C | 3,750,909 | 419,869 |
| Events in quadrant D | 3,668,993 | 409,448 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12819 | 2 |
| B | 0 | 13364 | 1 |
| C | 0 | 14628 | 1 |
| D | 0 | 14538 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5990 | 89 | 1.485810% |
| B | 5991 | 118 | 1.969621% |
| C | 5991 | 304 | 5.074278% |
| D | 5991 | 236 | 3.939242% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7335 | 5991 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7336 | 5992 | 4 | 4 | 0.05% | 0.07% |  |
| C | 7336 | 5992 | 167 | 167 | 2.28% | 2.79% |  |
| D | 7336 | 5992 | 170 | 170 | 2.32% | 2.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 8991 | 49.65 | 830 | 818 | 164.6 |
| A | 0 | 226 | 7064 | 37.94 | 830 | 818 | 164.6 |
| A | 3 | 137 | 6563 | 34.9 | 830 | 818 | 164.6 |
| B | 4 | 171 | 80000 | 511.58 | 825 | 811 | 154.8 |
| B | 3 | 64 | 27083 | 169.72 | 825 | 811 | 154.8 |
| B | 12 | 111 | 17756 | 109.47 | 825 | 811 | 154.8 |
| C | 10 | 22 | 622512 | 3500.68 | 769 | 776 | 177.6 |
| C | 14 | 238 | 125357 | 701.45 | 769 | 776 | 177.6 |
| C | 0 | 10 | 6684 | 33.26 | 769 | 776 | 177.6 |
| D | 1 | 52 | 671892 | 3643.19 | 773 | 753 | 184.2 |
| D | 2 | 136 | 41903 | 223.38 | 773 | 753 | 184.2 |
| D | 13 | 172 | 28667 | 151.53 | 773 | 753 | 184.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
