| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_149T01_9000003304_22334cztM0_level2.evt | modeM0/AS1A07_149T01_9000003304_22334cztM0_level2_quad_clean.evt |
| Size (bytes) | 406,431,360 | 100,912,320 |
| Size | 387.6 MB | 96.2 MB |
| Events in quadrant A | 2,829,716 | 666,140 |
| Events in quadrant B | 2,978,463 | 696,891 |
| Events in quadrant C | 2,971,296 | 663,541 |
| Events in quadrant D | 3,149,834 | 639,199 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 114 | 0 |
| B | 0 | 114 | 0 |
| C | 0 | 114 | 0 |
| D | 0 | 114 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11764 | 1 |
| B | 0 | 12205 | 1 |
| C | 0 | 12105 | 1 |
| D | 0 | 12907 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5580 | 19 | 0.340502% |
| B | 5580 | 50 | 0.896057% |
| C | 5580 | 66 | 1.182796% |
| D | 5580 | 81 | 1.451613% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6950 | 5581 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6950 | 5581 | 4 | 4 | 0.06% | 0.07% |  |
| C | 6950 | 5581 | 0 | 0 | 0.00% | 0.00% |  |
| D | 6950 | 5581 | 57 | 57 | 0.82% | 1.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 7141 | 43.92 | 733 | 720 | 146.2 |
| A | 0 | 226 | 6281 | 38.04 | 733 | 720 | 146.2 |
| A | 3 | 137 | 5681 | 33.93 | 733 | 720 | 146.2 |
| B | 0 | 190 | 16706 | 116.99 | 749 | 732 | 136.5 |
| B | 12 | 111 | 15860 | 110.8 | 749 | 732 | 136.5 |
| B | 6 | 36 | 14705 | 102.34 | 749 | 732 | 136.5 |
| C | 14 | 238 | 117866 | 700.82 | 729 | 735 | 167.1 |
| C | 0 | 10 | 9313 | 51.32 | 729 | 735 | 167.1 |
| C | 13 | 61 | 5065 | 25.9 | 729 | 735 | 167.1 |
| D | 1 | 52 | 252868 | 1468.93 | 720 | 700 | 171.7 |
| D | 13 | 174 | 128250 | 743.01 | 720 | 700 | 171.7 |
| D | 13 | 172 | 27817 | 157.96 | 720 | 700 | 171.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
