| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_007T04_9000003310_22361cztM0_level2.evt | modeM0/AS1A07_007T04_9000003310_22361cztM0_level2_quad_clean.evt |
| Size (bytes) | 463,910,400 | 96,791,040 |
| Size | 442.4 MB | 92.3 MB |
| Events in quadrant A | 3,088,548 | 637,945 |
| Events in quadrant B | 3,798,276 | 636,247 |
| Events in quadrant C | 3,128,452 | 622,892 |
| Events in quadrant D | 3,611,167 | 599,164 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13306 | 2 |
| B | 0 | 15487 | 2 |
| C | 0 | 13352 | 2 |
| D | 0 | 15088 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6226 | 30 | 0.481850% |
| B | 6226 | 228 | 3.662062% |
| C | 6226 | 85 | 1.365243% |
| D | 6226 | 99 | 1.590106% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7466 | 6227 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7466 | 6226 | 173 | 173 | 2.32% | 2.78% |  |
| C | 7466 | 6227 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7466 | 6227 | 74 | 74 | 0.99% | 1.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 49391 | 311.21 | 788 | 773 | 156.2 |
| A | 13 | 254 | 8763 | 51.15 | 788 | 773 | 156.2 |
| A | 0 | 226 | 6733 | 38.15 | 788 | 773 | 156.2 |
| B | 3 | 64 | 679501 | 4641.05 | 782 | 763 | 146.2 |
| B | 0 | 229 | 18142 | 118.83 | 782 | 763 | 146.2 |
| B | 12 | 111 | 16911 | 110.41 | 782 | 763 | 146.2 |
| C | 14 | 238 | 122641 | 682.93 | 767 | 773 | 178.5 |
| C | 0 | 10 | 12062 | 63.26 | 767 | 773 | 178.5 |
| C | 13 | 61 | 5439 | 26.15 | 767 | 773 | 178.5 |
| D | 1 | 52 | 372266 | 2000.66 | 770 | 749 | 185.7 |
| D | 7 | 38 | 236501 | 1269.55 | 770 | 749 | 185.7 |
| D | 12 | 227 | 47670 | 252.68 | 770 | 749 | 185.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
