| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_007T04_9000003310_22372cztM0_level2.evt | modeM0/AS1A07_007T04_9000003310_22372cztM0_level2_quad_clean.evt |
| Size (bytes) | 456,753,600 | 98,807,040 |
| Size | 435.6 MB | 94.2 MB |
| Events in quadrant A | 3,076,466 | 648,467 |
| Events in quadrant B | 3,152,737 | 654,266 |
| Events in quadrant C | 3,121,283 | 625,068 |
| Events in quadrant D | 4,032,725 | 603,237 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13532 | 1 |
| B | 0 | 13640 | 1 |
| C | 0 | 13527 | 1 |
| D | 0 | 16353 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6608 | 39 | 0.590194% |
| B | 6608 | 44 | 0.665860% |
| C | 6608 | 75 | 1.134988% |
| D | 6609 | 205 | 3.101831% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7473 | 6608 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7473 | 6608 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7473 | 6608 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7474 | 6609 | 125 | 125 | 1.67% | 1.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9106 | 51.48 | 798 | 777 | 161.8 |
| A | 0 | 226 | 6987 | 38.38 | 798 | 777 | 161.8 |
| A | 3 | 137 | 6918 | 37.96 | 798 | 777 | 161.8 |
| B | 12 | 111 | 18399 | 116.92 | 793 | 772 | 150.8 |
| B | 0 | 190 | 18184 | 115.49 | 793 | 772 | 150.8 |
| B | 11 | 111 | 16127 | 101.85 | 793 | 772 | 150.8 |
| C | 14 | 238 | 121678 | 672.09 | 766 | 769 | 179.9 |
| C | 0 | 207 | 10853 | 56.05 | 766 | 769 | 179.9 |
| C | 13 | 61 | 5411 | 25.8 | 766 | 769 | 179.9 |
| D | 1 | 52 | 915281 | 4868.98 | 773 | 751 | 187.8 |
| D | 13 | 172 | 150656 | 798.1 | 773 | 751 | 187.8 |
| D | 2 | 234 | 29341 | 152.21 | 773 | 751 | 187.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
