| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_007T04_9000003310_22375cztM0_level2.evt | modeM0/AS1A07_007T04_9000003310_22375cztM0_level2_quad_clean.evt |
| Size (bytes) | 498,836,160 | 97,773,120 |
| Size | 475.7 MB | 93.2 MB |
| Events in quadrant A | 3,130,127 | 647,818 |
| Events in quadrant B | 3,211,340 | 655,438 |
| Events in quadrant C | 3,179,689 | 627,761 |
| Events in quadrant D | 5,148,635 | 580,173 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13613 | 2 |
| B | 0 | 13823 | 2 |
| C | 0 | 13657 | 2 |
| D | 0 | 19841 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6442 | 49 | 0.760633% |
| B | 6442 | 55 | 0.853772% |
| C | 6442 | 93 | 1.443651% |
| D | 6442 | 460 | 7.140640% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7622 | 6442 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7622 | 6442 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7622 | 6442 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7622 | 6442 | 402 | 402 | 5.27% | 6.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 11946 | 69.33 | 807 | 793 | 160.9 |
| A | 13 | 254 | 10360 | 59.47 | 807 | 793 | 160.9 |
| A | 3 | 1 | 8059 | 45.16 | 807 | 793 | 160.9 |
| B | 0 | 190 | 25969 | 167.07 | 805 | 783 | 150.8 |
| B | 12 | 111 | 17521 | 111.03 | 805 | 783 | 150.8 |
| B | 0 | 245 | 17300 | 109.56 | 805 | 783 | 150.8 |
| C | 14 | 238 | 122976 | 672.8 | 781 | 784 | 181.6 |
| C | 0 | 10 | 7925 | 39.32 | 781 | 784 | 181.6 |
| C | 13 | 61 | 5506 | 26.0 | 781 | 784 | 181.6 |
| D | 1 | 52 | 2082882 | 11156.56 | 770 | 749 | 186.6 |
| D | 7 | 38 | 74531 | 395.34 | 770 | 749 | 186.6 |
| D | 5 | 32 | 44261 | 233.15 | 770 | 749 | 186.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
