| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_144T02_9000003340_22470cztM0_level2.evt | modeM0/AS1A07_144T02_9000003340_22470cztM0_level2_quad_clean.evt |
| Size (bytes) | 467,118,720 | 90,936,000 |
| Size | 445.5 MB | 86.7 MB |
| Events in quadrant A | 3,247,665 | 572,276 |
| Events in quadrant B | 3,306,891 | 585,887 |
| Events in quadrant C | 3,272,067 | 561,745 |
| Events in quadrant D | 3,848,989 | 550,878 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14352 | 1 |
| B | 0 | 14435 | 1 |
| C | 0 | 14353 | 1 |
| D | 0 | 16485 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6925 | 96 | 1.386282% |
| B | 6926 | 145 | 2.093560% |
| C | 6926 | 153 | 2.209067% |
| D | 6926 | 117 | 1.689287% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7160 | 6925 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7161 | 6926 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7161 | 6926 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7161 | 6926 | 33 | 33 | 0.46% | 0.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 45932 | 267.17 | 829 | 812 | 168.9 |
| A | 13 | 254 | 8607 | 46.16 | 829 | 812 | 168.9 |
| A | 3 | 1 | 8310 | 44.4 | 829 | 812 | 168.9 |
| B | 0 | 244 | 22262 | 133.19 | 829 | 807 | 161.1 |
| B | 12 | 111 | 20117 | 119.87 | 829 | 807 | 161.1 |
| B | 11 | 111 | 18223 | 108.12 | 829 | 807 | 161.1 |
| C | 14 | 238 | 124226 | 647.87 | 798 | 802 | 190.5 |
| C | 9 | 54 | 17456 | 87.42 | 798 | 802 | 190.5 |
| C | 8 | 128 | 11065 | 53.87 | 798 | 802 | 190.5 |
| D | 1 | 52 | 747092 | 3768.84 | 810 | 786 | 198.0 |
| D | 2 | 234 | 29166 | 143.32 | 810 | 786 | 198.0 |
| D | 13 | 172 | 19702 | 95.52 | 810 | 786 | 198.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
