| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_144T02_9000003340_22488cztM0_level2.evt | modeM0/AS1A07_144T02_9000003340_22488cztM0_level2_quad_clean.evt |
| Size (bytes) | 398,211,840 | 62,487,360 |
| Size | 379.8 MB | 59.6 MB |
| Events in quadrant A | 3,024,982 | 485,528 |
| Events in quadrant B | 3,083,711 | 497,269 |
| Events in quadrant C | 922,437 | 66 |
| Events in quadrant D | 4,586,604 | 460,545 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12997 | 1 |
| B | 0 | 13083 | 1 |
| C | 0 | 6403 | 1 |
| D | 0 | 17719 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6401 | 48 | 0.749883% |
| B | 6402 | 66 | 1.030928% |
| C | 6402 | 6402 | 100.000000% |
| D | 6402 | 405 | 6.326148% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7276 | 6401 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7277 | 6402 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7276 | 6401 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7277 | 6402 | 332 | 332 | 4.56% | 5.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 8963 | 51.38 | 783 | 765 | 159.6 |
| A | 3 | 137 | 6827 | 37.99 | 783 | 765 | 159.6 |
| A | 0 | 226 | 6579 | 36.44 | 783 | 765 | 159.6 |
| B | 12 | 111 | 18512 | 118.2 | 779 | 759 | 150.2 |
| B | 11 | 111 | 16636 | 105.71 | 779 | 759 | 150.2 |
| B | 14 | 111 | 14662 | 92.56 | 779 | 759 | 150.2 |
| C | 7 | 119 | 910346 | 685653.11 | 2 | 2 | 1.3 |
| C | 7 | 226 | 1920 | 1444.6 | 2 | 2 | 1.3 |
| C | 14 | 238 | 1044 | 784.81 | 2 | 2 | 1.3 |
| D | 1 | 52 | 1682539 | 9155.31 | 749 | 726 | 183.7 |
| D | 2 | 234 | 28006 | 148.5 | 749 | 726 | 183.7 |
| D | 11 | 66 | 20016 | 105.01 | 749 | 726 | 183.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
