| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_144T02_9000003340_22502cztM0_level2.evt | modeM0/AS1A07_144T02_9000003340_22502cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,075,608,000 | 194,898,240 |
| Size | 1.0 GB | 185.9 MB |
| Events in quadrant A | 8,501,289 | 1,432,063 |
| Events in quadrant B | 8,906,155 | 1,463,702 |
| Events in quadrant C | 4,384,714 | 373,107 |
| Events in quadrant D | 9,535,990 | 1,374,179 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 372 | 0 |
| B | 0 | 372 | 0 |
| C | 0 | 372 | 0 |
| D | 0 | 372 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 37138 | 3 |
| B | 0 | 38120 | 3 |
| C | 0 | 23733 | 3 |
| D | 0 | 40660 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18253 | 137 | 0.750562% |
| B | 18253 | 225 | 1.232674% |
| C | 18085 | 12912 | 71.396185% |
| D | 18254 | 264 | 1.446258% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20213 | 18253 | 7 | 7 | 0.03% | 0.04% |  |
| B | 20213 | 18253 | 55 | 55 | 0.27% | 0.30% |  |
| C | 20213 | 18085 | 2 | 2 | 0.01% | 0.01% |  |
| D | 20214 | 18254 | 147 | 147 | 0.73% | 0.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 240 | 33890 | 72.23 | 2189 | 2143 | 439.6 |
| A | 13 | 254 | 25860 | 53.96 | 2189 | 2143 | 439.6 |
| A | 3 | 137 | 19419 | 39.3 | 2189 | 2143 | 439.6 |
| B | 5 | 172 | 221833 | 528.39 | 2176 | 2120 | 415.8 |
| B | 15 | 33 | 105691 | 249.08 | 2176 | 2120 | 415.8 |
| B | 12 | 111 | 52102 | 120.2 | 2176 | 2120 | 415.8 |
| C | 7 | 119 | 1827001 | 12384.82 | 619 | 623 | 147.5 |
| C | 14 | 238 | 99169 | 668.25 | 619 | 623 | 147.5 |
| C | 0 | 10 | 31690 | 210.67 | 619 | 623 | 147.5 |
| D | 1 | 52 | 828955 | 1594.54 | 2128 | 2064 | 518.6 |
| D | 2 | 136 | 301043 | 576.54 | 2128 | 2064 | 518.6 |
| D | 13 | 172 | 163743 | 311.77 | 2128 | 2064 | 518.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
