| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_003T01_9000003342_22518cztM0_level2.evt | modeM0/AS1A08_003T01_9000003342_22518cztM0_level2_quad_clean.evt |
| Size (bytes) | 440,398,080 | 79,485,120 |
| Size | 420.0 MB | 75.8 MB |
| Events in quadrant A | 3,042,704 | 495,758 |
| Events in quadrant B | 3,135,490 | 507,671 |
| Events in quadrant C | 3,102,059 | 490,286 |
| Events in quadrant D | 3,634,101 | 478,663 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12855 | 1 |
| B | 0 | 13076 | 1 |
| C | 0 | 12957 | 1 |
| D | 0 | 14729 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6227 | 54 | 0.867191% |
| B | 6228 | 64 | 1.027617% |
| C | 6228 | 75 | 1.204239% |
| D | 6228 | 192 | 3.082852% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7277 | 6227 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7278 | 6228 | 11 | 11 | 0.15% | 0.18% |  |
| C | 7278 | 6228 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7278 | 6228 | 143 | 143 | 1.96% | 2.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9810 | 57.28 | 789 | 773 | 157.8 |
| A | 0 | 226 | 6870 | 38.65 | 789 | 773 | 157.8 |
| A | 3 | 137 | 6734 | 37.79 | 789 | 773 | 157.8 |
| B | 0 | 197 | 35855 | 235.06 | 783 | 765 | 149.3 |
| B | 12 | 111 | 18274 | 117.29 | 783 | 765 | 149.3 |
| B | 11 | 111 | 16379 | 104.6 | 783 | 765 | 149.3 |
| C | 14 | 238 | 121232 | 672.45 | 764 | 771 | 179.1 |
| C | 13 | 61 | 5386 | 25.76 | 764 | 771 | 179.1 |
| C | 0 | 10 | 4542 | 21.05 | 764 | 771 | 179.1 |
| D | 1 | 52 | 616016 | 3256.53 | 768 | 747 | 188.9 |
| D | 2 | 136 | 49886 | 260.09 | 768 | 747 | 188.9 |
| D | 12 | 227 | 35725 | 185.13 | 768 | 747 | 188.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
