| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_049T01_9000003344_22542cztM0_level2.evt | modeM0/AS1A07_049T01_9000003344_22542cztM0_level2_quad_clean.evt |
| Size (bytes) | 812,410,560 | 88,047,360 |
| Size | 774.8 MB | 84.0 MB |
| Events in quadrant A | 3,812,789 | 553,079 |
| Events in quadrant B | 4,073,312 | 559,960 |
| Events in quadrant C | 3,952,734 | 538,858 |
| Events in quadrant D | 12,216,369 | 450,504 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16719 | 2 |
| B | 0 | 17279 | 2 |
| C | 0 | 16850 | 2 |
| D | 0 | 41796 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 168 | 0 |
| B | 0 | 168 | 0 |
| C | 0 | 168 | 0 |
| D | 0 | 168 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8099 | 95 | 1.172984% |
| B | 8099 | 188 | 2.321274% |
| C | 8099 | 155 | 1.913817% |
| D | 8100 | 3376 | 41.679012% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8819 | 8099 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8819 | 8099 | 22 | 22 | 0.25% | 0.27% |  |
| C | 8819 | 8099 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8819 | 8099 | 3279 | 3279 | 37.18% | 40.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11752 | 53.74 | 987 | 960 | 200.8 |
| A | 3 | 137 | 8887 | 39.47 | 987 | 960 | 200.8 |
| A | 0 | 226 | 8409 | 37.09 | 987 | 960 | 200.8 |
| B | 5 | 172 | 105211 | 543.28 | 987 | 959 | 191.9 |
| B | 15 | 33 | 63948 | 328.25 | 987 | 959 | 191.9 |
| B | 12 | 111 | 23698 | 118.5 | 987 | 959 | 191.9 |
| C | 14 | 238 | 147841 | 650.46 | 957 | 962 | 225.8 |
| C | 0 | 207 | 51894 | 225.55 | 957 | 962 | 225.8 |
| C | 8 | 128 | 13177 | 54.09 | 957 | 962 | 225.8 |
| D | 7 | 223 | 8362215 | 52198.22 | 659 | 641 | 160.2 |
| D | 1 | 52 | 1207858 | 7536.21 | 659 | 641 | 160.2 |
| D | 13 | 249 | 61052 | 377.12 | 659 | 641 | 160.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
