| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_054T01_9000003348_22571cztM0_level2.evt | modeM0/AS1A07_054T01_9000003348_22571cztM0_level2_quad_clean.evt |
| Size (bytes) | 591,523,200 | 152,046,720 |
| Size | 564.1 MB | 145.0 MB |
| Events in quadrant A | 4,308,220 | 1,014,503 |
| Events in quadrant B | 4,497,717 | 1,016,327 |
| Events in quadrant C | 4,215,693 | 985,956 |
| Events in quadrant D | 4,294,463 | 976,617 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 182 | 0 |
| B | 0 | 182 | 0 |
| C | 0 | 182 | 0 |
| D | 0 | 182 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18923 | 2 |
| B | 0 | 19455 | 2 |
| C | 0 | 18610 | 2 |
| D | 0 | 19136 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8807 | 53 | 0.601794% |
| B | 8808 | 166 | 1.884650% |
| C | 8808 | 114 | 1.294278% |
| D | 8808 | 43 | 0.488193% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9452 | 8808 | 2 | 2 | 0.02% | 0.02% |  |
| B | 9453 | 8809 | 13 | 13 | 0.14% | 0.15% |  |
| C | 9453 | 8809 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9453 | 8809 | 16 | 16 | 0.17% | 0.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 34 | 235146 | 1099.23 | 1054 | 1032 | 213.0 |
| A | 13 | 254 | 14899 | 65.11 | 1054 | 1032 | 213.0 |
| A | 0 | 226 | 9063 | 37.71 | 1054 | 1032 | 213.0 |
| B | 15 | 33 | 241201 | 1203.43 | 1052 | 1025 | 199.6 |
| B | 15 | 35 | 34661 | 168.53 | 1052 | 1025 | 199.6 |
| B | 0 | 245 | 34626 | 168.36 | 1052 | 1025 | 199.6 |
| C | 14 | 238 | 162121 | 672.2 | 1020 | 1024 | 239.7 |
| C | 10 | 222 | 53699 | 219.79 | 1020 | 1024 | 239.7 |
| C | 10 | 22 | 10599 | 39.95 | 1020 | 1024 | 239.7 |
| D | 1 | 52 | 163890 | 654.07 | 1030 | 1000 | 249.0 |
| D | 2 | 136 | 114289 | 454.9 | 1030 | 1000 | 249.0 |
| D | 2 | 234 | 38148 | 149.16 | 1030 | 1000 | 249.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
