| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_054T01_9000003348_22578cztM0_level2.evt | modeM0/AS1A07_054T01_9000003348_22578cztM0_level2_quad_clean.evt |
| Size (bytes) | 463,645,440 | 101,200,320 |
| Size | 442.2 MB | 96.5 MB |
| Events in quadrant A | 3,172,518 | 673,798 |
| Events in quadrant B | 3,299,699 | 670,456 |
| Events in quadrant C | 3,246,547 | 642,633 |
| Events in quadrant D | 3,892,938 | 636,321 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13499 | 1 |
| B | 0 | 13806 | 1 |
| C | 0 | 13695 | 1 |
| D | 0 | 15876 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6324 | 52 | 0.822264% |
| B | 6325 | 64 | 1.011858% |
| C | 6325 | 84 | 1.328063% |
| D | 6325 | 112 | 1.770751% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7519 | 6325 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7520 | 6326 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7520 | 6326 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7520 | 6326 | 48 | 48 | 0.64% | 0.76% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 10425 | 58.18 | 823 | 807 | 165.3 |
| A | 0 | 226 | 7181 | 38.56 | 823 | 807 | 165.3 |
| A | 3 | 137 | 6519 | 34.55 | 823 | 807 | 165.3 |
| B | 15 | 33 | 85007 | 557.29 | 807 | 787 | 151.1 |
| B | 0 | 228 | 20948 | 133.41 | 807 | 787 | 151.1 |
| B | 0 | 230 | 19459 | 123.55 | 807 | 787 | 151.1 |
| C | 14 | 238 | 125550 | 690.11 | 784 | 790 | 180.8 |
| C | 10 | 222 | 46772 | 254.35 | 784 | 790 | 180.8 |
| C | 10 | 22 | 13941 | 72.74 | 784 | 790 | 180.8 |
| D | 1 | 52 | 551315 | 2876.59 | 798 | 776 | 191.4 |
| D | 12 | 33 | 183744 | 956.01 | 798 | 776 | 191.4 |
| D | 9 | 85 | 49933 | 256.84 | 798 | 776 | 191.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
