| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_007T01_9000003362_22651cztM0_level2.evt | modeM0/AS1A08_007T01_9000003362_22651cztM0_level2_quad_clean.evt |
| Size (bytes) | 830,448,000 | 161,161,920 |
| Size | 792.0 MB | 153.7 MB |
| Events in quadrant A | 5,552,354 | 1,057,227 |
| Events in quadrant B | 5,780,537 | 1,066,953 |
| Events in quadrant C | 5,612,525 | 1,013,140 |
| Events in quadrant D | 7,469,250 | 990,952 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 220 | 0 |
| B | 0 | 220 | 0 |
| C | 0 | 220 | 0 |
| D | 0 | 220 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23397 | 2 |
| B | 0 | 23845 | 2 |
| C | 0 | 23530 | 3 |
| D | 0 | 29671 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10875 | 92 | 0.845977% |
| B | 10875 | 95 | 0.873563% |
| C | 10874 | 156 | 1.434615% |
| D | 10874 | 222 | 2.041567% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 13305 | 10877 | 0 | 0 | 0.00% | 0.00% |  |
| B | 13305 | 10877 | 4 | 4 | 0.03% | 0.04% |  |
| C | 13304 | 10876 | 5 | 5 | 0.04% | 0.05% |  |
| D | 13304 | 10876 | 126 | 126 | 0.95% | 1.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 19972 | 65.28 | 1437 | 1407 | 284.4 |
| A | 3 | 1 | 14356 | 45.53 | 1437 | 1407 | 284.4 |
| A | 0 | 226 | 12760 | 39.92 | 1437 | 1407 | 284.4 |
| B | 0 | 219 | 113397 | 429.99 | 1415 | 1386 | 260.5 |
| B | 0 | 190 | 47501 | 177.03 | 1415 | 1386 | 260.5 |
| B | 12 | 111 | 29482 | 107.85 | 1415 | 1386 | 260.5 |
| C | 14 | 238 | 220292 | 700.9 | 1364 | 1375 | 312.3 |
| C | 10 | 22 | 41568 | 128.68 | 1364 | 1375 | 312.3 |
| C | 0 | 10 | 12909 | 36.93 | 1364 | 1375 | 312.3 |
| D | 1 | 52 | 1852916 | 5479.07 | 1397 | 1355 | 337.9 |
| D | 12 | 233 | 124521 | 364.47 | 1397 | 1355 | 337.9 |
| D | 13 | 172 | 66891 | 193.93 | 1397 | 1355 | 337.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
