| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_007T01_9000003362_22677cztM0_level2.evt | modeM0/AS1A08_007T01_9000003362_22677cztM0_level2_quad_clean.evt |
| Size (bytes) | 970,424,640 | 134,029,440 |
| Size | 925.5 MB | 127.8 MB |
| Events in quadrant A | 4,425,881 | 915,794 |
| Events in quadrant B | 4,804,840 | 925,938 |
| Events in quadrant C | 4,815,208 | 881,899 |
| Events in quadrant D | 14,681,801 | 655,647 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 196 | 0 |
| B | 0 | 196 | 0 |
| C | 0 | 196 | 0 |
| D | 0 | 196 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19848 | 2 |
| B | 0 | 20903 | 3 |
| C | 0 | 20637 | 2 |
| D | 0 | 50256 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 9798 | 17 | 0.173505% |
| B | 9797 | 62 | 0.632847% |
| C | 9797 | 101 | 1.030928% |
| D | 9797 | 3719 | 37.960600% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 10363 | 9799 | 0 | 0 | 0.00% | 0.00% |  |
| B | 10362 | 9798 | 6 | 6 | 0.06% | 0.06% |  |
| C | 10362 | 9798 | 18 | 18 | 0.17% | 0.18% |  |
| D | 10362 | 9798 | 3446 | 3446 | 33.26% | 35.17% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 17283 | 70.38 | 1145 | 1122 | 229.6 |
| A | 0 | 226 | 9779 | 37.7 | 1145 | 1122 | 229.6 |
| A | 3 | 137 | 9537 | 36.65 | 1145 | 1122 | 229.6 |
| B | 0 | 219 | 95567 | 430.98 | 1146 | 1115 | 219.2 |
| B | 0 | 190 | 60420 | 270.6 | 1146 | 1115 | 219.2 |
| B | 0 | 230 | 46240 | 205.9 | 1146 | 1115 | 219.2 |
| C | 14 | 238 | 172041 | 658.83 | 1105 | 1110 | 259.4 |
| C | 10 | 22 | 148225 | 567.03 | 1105 | 1110 | 259.4 |
| C | 9 | 54 | 146247 | 559.41 | 1105 | 1110 | 259.4 |
| D | 7 | 238 | 10381357 | 45399.38 | 934 | 904 | 228.6 |
| D | 1 | 52 | 277197 | 1208.38 | 934 | 904 | 228.6 |
| D | 13 | 172 | 158003 | 687.08 | 934 | 904 | 228.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
