| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A08_007T01_9000003362_22706cztM0_level2.evt | modeM0/AS1A08_007T01_9000003362_22706cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,129,176,000 | 211,625,280 |
| Size | 1.1 GB | 201.8 MB |
| Events in quadrant A | 7,291,705 | 1,350,276 |
| Events in quadrant B | 7,604,678 | 1,368,926 |
| Events in quadrant C | 7,554,415 | 1,311,848 |
| Events in quadrant D | 10,668,986 | 1,279,720 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 322 | 0 |
| B | 0 | 322 | 0 |
| C | 0 | 322 | 0 |
| D | 0 | 322 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32293 | 3 |
| B | 0 | 33094 | 3 |
| C | 0 | 32671 | 4 |
| D | 0 | 42428 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15937 | 43 | 0.269812% |
| B | 15937 | 78 | 0.489427% |
| C | 15936 | 126 | 0.790663% |
| D | 15936 | 607 | 3.808986% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 17252 | 15939 | 0 | 0 | 0.00% | 0.00% |  |
| B | 17252 | 15939 | 3 | 3 | 0.02% | 0.02% |  |
| C | 17251 | 15938 | 9 | 9 | 0.05% | 0.06% |  |
| D | 17251 | 15938 | 461 | 461 | 2.67% | 2.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 28897 | 71.51 | 1881 | 1836 | 378.4 |
| A | 14 | 235 | 24966 | 61.12 | 1881 | 1836 | 378.4 |
| A | 0 | 226 | 16386 | 38.45 | 1881 | 1836 | 378.4 |
| B | 15 | 33 | 56613 | 154.07 | 1882 | 1836 | 355.5 |
| B | 0 | 245 | 47919 | 129.62 | 1882 | 1836 | 355.5 |
| B | 12 | 111 | 41610 | 111.87 | 1882 | 1836 | 355.5 |
| C | 14 | 238 | 285192 | 672.03 | 1813 | 1826 | 421.7 |
| C | 10 | 22 | 88298 | 205.08 | 1813 | 1826 | 421.7 |
| C | 9 | 54 | 81175 | 188.18 | 1813 | 1826 | 421.7 |
| D | 1 | 52 | 2055716 | 4646.32 | 1821 | 1766 | 442.1 |
| D | 12 | 233 | 954826 | 2155.95 | 1821 | 1766 | 442.1 |
| D | 12 | 227 | 433982 | 977.73 | 1821 | 1766 | 442.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
